Item | unit | HDT5340THB-42/4 | HDT5380THB-45/5 |
output in theory | m3/h | 125 | 125 |
index of the pump carry capacity | Mpa.m3/h | 586 | 586 |
theoretic pumping pssure | Mpa | 8.5 | 8.5 |
bucket volume | L | 700 | 700 |
height of top surface of bucket | mm | 1400 | 1400 |
model of distribution valve | S Valve | S Valve | |
max. operation radius | m | 38 | 40.7 |
max. operation height | m | 41.8 | 44.7 |
max. operation depth | m | 29 | 31.3 |
open height of boom | mm | 8600 | 8495 |
diameter of delivery pipe | mm | 125 | 125 |
length of hose pipe | m | 4 | 3 |
rotary range of boom | 370° | 365° | |
quantity of boom | 4 | 5 | |
rotary angle of each boom | ° | 92/180/180/240 | 91/180/180/180/270 |
wire line control distance | m | 33 | 33 |
remote control distance | m | 200 | 200 |
max. speed | km/h | 85 | 85 |
min. turn radius | mm | 11900 | 11900 |
brake distance | m | 10 | 10 |
approach angle | ° | 16 | 16 |
departure angle | ° | 11 | 11 |
chassis model | ISUZU CYH51Y | ISUZU CYH51Y | |
max. engine output power | kw | 287(1800r/min) | 287(1800r/min) |
max. engine output torque | n.m | 1863(1100r/min) | 1863(1100r/min) |
max. gradient ability | % | 37 | 35 |
fuel consumption | L/100km | 38 | 40 |
out dimension (LxWxH) | mm | 13800x2490x3995 | 13100x2500x3900 |
total weight | kg | 34500 | 38000 |
