Transportable Gas Cylinder Racks

Transportable Gas Cylinder Racks,Vertical/Horizontal Manifolded Cylinder Bundles.

CBMTECH manifolded cylinder bundles have been successfully used in the field for over 20 years by all the largest gas companies, the smallest independent operators and major mining companies. Our unique modular design greatly reduces handling, increases mobility and cuts transportation costs resulting in increased productivity and reduced operational costs.

MODEL	CYLINDERS
9 PIECES	3*3
12 PIECES	3*4
15 PIECES	3*5
16 PIECES	4*4
18 PIECES	3*6
20 PIECES	4*5
25 PIECES	5*5
30 PIECES	5*6
36 PIECES	6*6
40 PIECES	5*8

Manifolded cylinder bundles could reduce your maintenance and repair costs by 80% over the lifetime of the unit. Our modular, bolted design allows flexibility to tailor the size of the bundle to suit your cylinder requirements. Bolted parts allow quick and easy isolation and replacement of damaged parts. This reduces down-time and eliminates the need for welding, specialist tools and operators.
Some important facts:
· CBMTECH manifolds are designed for aworking pssure from 15 to 30MPa;
· Our exclusive manifold design is interchangeable with all gases;
· 100% of all manifolds are tested to twice the working pssure;
· We can design bundles to suit any customers' requirements.
· Our gas cylinder bundle frames are all modular, hot dipped galvanised inside and out to 70microns.
· All manifolds are cleaned to oxygen standard;
· All our products come with a5-year guarantee on CBMTECH parts and labour.
· CBMTECH design eliminates cylinder and manifold abuse saving you down time, replacement, repair costs and pserves the life of your HP gas cylinders.
Gas Cylinder Racks/Bundles:
*Certification Provided: Approval DNV 2.7-1 and EN 12709 Standard;
*Corten steel with CSC plate;
*12/16/18/30 per bundle;
*Tare Weight: 750kg;
*Rack Material: Corten steel with CSC plate.

Ref. Main Specifications
	Dimensions	M
External	Length	1.428
	Width	1.158
	Height	2.350
Internal	Length	1.218
	Width	0.948
	Height	1.931
Inside Cubic Capacity		CU.M
		16
		KG
Maximum Gross Weight		2,700
Tare Weight		750
Maximum Payload		2,000

*about Us:
We are a professional manufacturer and supplier of Gas Cylinders Regulators, Oxygen Flowmeters,Medical Oxygen Flow Regulators, Medical Oxygen Kits, Oxygen Intake Devices, Gas O2 Valves, Medical Pin Index Valves, Medical Gas O2 Supply System Products, Gas O2 Cylinder Trolleys, Gas O2 Outlets, Ceiling Medical Pendants, Medical Gas Oxygen Respiratory Products and etc.

Advantages we have:
-1)Original Manuacturer: Our factories have professional equipments for gas cylinders, medical oxygen regulators, like Punch, CNC Machines, and etc.;
-2)Large Output capability: We have the capability to produce more than 50, 000pcs of Gas Cylinders & 30, 000 PCS Medical Oxygen Cylinders each month;
-3)Quality Control: With ISO9001: 2008, ISO 13485 Quality Management system; All products have been tested before out of our factories;
-4)Cost Advantages: We have cost advantage because our professional and scale economy;
-5)Series: We have different series and models, for different standards in different countries;
-6)Small order can be acceptable: M. O. Q. =50 PCS;
-7)Exporting experience: We have over 5 years' experience for exporting business.

What we can promise for you:
*High quality and security gas cylinders;
*Competitive unit price in the market;
*Fast delivery (3~4 weeks);
*Best after-sale service.

Anyway,should you have any intersts or some more info needed on ourmedical gas cylinders & allied gas items(gas cylinder valves,gas regulators,medical hospital central oxygen system products),you are really welcome to enquire us anytime!
