Heavy Duty Steel Seclective Pallet Rack From China Manufacturer

Aisle pallet racking is also called Location pallet racking which is of cut-in composite structure.

The upright made by continuous punching and rolling.

The frame is assembled by uprights and bracings and beams are fixed to uprights by hooks There are safety locks to fix beams and uprights tightly, protecting beams from dropping when loading goods with forklifts.

The height of each layer can be adjusted by 75mm freely, the capacity of each layer can be up to 4, 000kg.

Its convenient to load and unload pallets with goods on by using forklifts, Such forklifts as front-move forklift balance-weight forklift common forklift and stackers can be used to load and unload goods.

Steel panels, wooden panels and decking are also available for putting on beams instead of pallets.

Pallet racking is the most common storage system which is used in fields of manufacturing industry the third part logistics distribution centers supermarket and so on.

Pallet racking is the first choice when building high-position warehouses and AS/RS system.

frame	Height (2-13m)	Depth (600-1,400mm)
	Upright section: 80x60; 90 X70; 100 X65; 120 X87mm
	Thickness: 2.0/2.3/2.5/3.0mm
Beam	Length (1200-4000mm) ,popular size: 2300,2500,2700,3200,3600mm
	Beam section: 80 X50; 100 X50;110x50; 120 X50; 140 X50mm
	Thickness: 1.4--1.5mm
Load capacity	1-4Tons/Layer
Others	Pitch: 75mm,76.2mm - Delivery time: 14-20days - Payment term. T/T or L/C at sight - Necessary accessories: free(bolts &nuts, base plate, etc) - Packing: stretch film &carton -Surface treatment: powder coated, galvanization - Production capacity: 3000T/month - Main market: exported more than 40countries, such as AU, pH, SG, UK, India and etc. - Available in various colors/specifications/sizes

Route:
Our office and factory are located in Nanjing, Jiangsu Province, China
1) You can fly to Nanjing Airport directly. We will pick you up on Nanjing Lukou International airport;
2) You can fly to Shanghai Pudong International Airport then come to Nanjing by High-speed railway, then we will pick you up in Nanjing South Railway Station.
All our clients, from domestic or abroad, are warmly welcome to visit us!

AFQ:

1. What makes you different with others?

1) Our Excellent Service

For aquick, no hassle quote just send email to us

We promise to reply with aprice within 24 hours -sometimes even within the hour.

If you need an advice, just call our export office at 0086-25-51873961, we will answer your questions immediately.

2)Our quick manufacturing time

For Normal orders, we will promise to produce within 15 days.

As amanufactory, we can essure the delivery time according to the formal contract.

3)Our Special Export Design

We pay very much attention to the export packages. We have plastic clips on the beams to protect the beams from surface damage in the transportation, We have got the whole uprights wrapped with transparent plastic film.

4)Our Warranty Time

The High Standards in the Design and Manufacturing ensure us to support the products with a10-Year Warranty Time for your normal use, it is the Longest Manufacturer's Warranty !

2. What is delivery times?

This depends on the product. Typically standard products are delivered within 20 days.

The delivery time of the special products is according to the time of setting up of the tooling.

3.What is the term of payment?

1) T/T payment. 2) LC

4. May Iknow the status of my order?

Yes .We will send you information and photos at different production stage of your order. You will get the latest information in time.

5. Are samples available?

Yes, we can send some sections of samples for your reference by expss.

We are professional manufacturer of all types of Racking system since 1997, supply you with quality products at competitive prices. We would like to be your reliable supplier and trusted friends.
Thank you for your attention! If you have any concern or questions, kindly contact us at below Chat Window or add my Skype, we all help you out at the earliest.
