Medium Duty Racking Warehouse Metal Storage Rack

Structure:

1. Cut-in composite structure, standard cut-in units; Assembling and dismantling are simple and quick, high-strength steel panel by continuous punching and rolling; Shelving depth can be adjusted freely; Support bars are fixed to the bottom of the panel in order to reinforce the loading capacity, and there are filters in the front of the panel for use of reinforcing, making it look good.

2. The storage space of each layer can be divided freely by fixing separators to the holes on panel surface; Height of each level can be adjusted every 50mm easily, square upright, the capacity of each layer can be up to 500kg, widely used in every walk of life.

3. NM1A shelving is most suitable for building Mezzanine.

Length (mm)	Capacity of each layer(kg)
	900	1200	1500	1800
480	600	560	360	240
620	600	620	380	260
910	600	600	600	390
940	600	600	600	480
1220	600	600	600	520
Size of upright(mm)	55*55*1.5,Pitch=50, H=1.5,1.8,2.0,2.4,3,4.8(m)

We are professional manufacturer of all types of Racking system since 1997, supply you with quality products at competitive prices. We would like to be your reliable supplier and trusted friends.

Thank you for your attention! If you have any concern or questions, kindly contact us at below Chat Window, we all help you out at the earliest.
