4X2 HOWO 28m 33m concrete boom pump truck

4x2 HOWO 28m 33m concrete boom pump truck


Brief introduction of portable concrete mixer with pump
The truck mounted concrete pumpis also called concrete mixer pump,concrete mixer wth pump, portable concrete pump, mobile concrete mixer with pump, portable concrete mixer and pump, concrete pump mixer truck,etc.
Theconcrete mixer wth pump is multi-functional concrete truck. It is with fully automated operation system.It both can mix the concrete and can pump it to designated place, which greatly improve the efficiency. It also utilize diesel generator to drive,which can reduceenergy consumption, save cost.
The concrete mixer with pump is usually used to pump the concrete for various small scale building site,foundation piling ,civil architecture, road ,railway or other place.


Technique Parameters FOR High quality Construction Site use Concrete Mixer truck with pump

Model		Unit	HTC5196THBEQ
Vehicle parameter	Total Length	mm	9800
	Total Width	mm	2495
	Total Height	mm	3850
	Curb weight	kg	19000
Boom and legs parameter	max. operation height	m	32.2
	max. operation radius	m	28.6
	max. operation depth	m	20.8
	open height of boom	m	7.5
	first boom length and angle of rotation	m m/°	7120/90
	second boom length and angle of rotation;	m m/°	4570/180
	third boom length and angle of rotation;	m m/°	5200/245
	fourth boom length and angle of rotation;	m m/°	5150/230
	fifth boom length and angle of rotation	m m/°	5000/360
	arm folding mode		M mode
	turntable rotation angle	°	±365
	distance between front landing legs	mm	5850
	distance between rear landing legs	mm	5420
	front and rear legs longitudinal span	mm	6300
	leg opening mode		X-H
Pumping system parameter	output in theory	m3/h	68/90
	theoretic pumping pssure	Mpa	8
	Theoretical pumping times		26/19
	Conveying cylinder diameter	mm	200/230
	Transport cylinder stroke	mm	1800/2000
	Hydraulic system		open type
	Tank volume	Mpa	32
	Oil Tank volume	L	480
	Water Tank volume	L	450
	Pipe diameter	mm	125
	End hose length	mm	3000
	End hose diameter	mm	125
Chassis parameters	chassis model		ZZ1165M5117
	wheel base	mm	5000/5600
	Drive Type		4x2
	engine model		SINOTRUK WD615.62
	max. engine output power	HP	260
	emissions standards		Europe IV
	fuel tank capacity	L	30''''0
	max. speed	Km/h	90
	brake distance	m/km/h	≤10/30
