37M truck mounted concrete pump, ISUZU Concrete Pump Truck

37M truck mounted concrete pump, ISUZU Concrete Pump Truck
37m ISUZU truck mounted concrete pump, concrete pump truck

We're one specialist truck refitting and semi trailer manufacturer in China, we could supply various special purpose trucks and semi trailers. Our products are always popular in China several years.

From 2005, China allow exporting completed truck and semitrailer. We established overseas department that year and exported more than 30 counties promptly. Our products got almost clients' love and admiration. We appciate our clients' fully trust to us, and remember the responsibility every moment.

There're too much processes need to do during producing, we never dare to reduce anyone. And we never dare to reduce any material although it's expensive. All of these only for ensure the high quality and excellent performance.

Respectful,Faithful,Studious,Innovative .Our progress never could leave your supporting. Warmly welcome your coming!




Packaging & Delivery
Packaging Detail: Packed in nude, use RORO or Bulk boat.
Delivery Detail: 60days
Specifications
ISUZU truck supplier Qingdao HETANCH
1. ISUZU engine, 6WF1A
2. Japan original chassis
3. 6x4 driving type
4. High quality

ISUZUConcrete Pump Truck supplier Qingdao HETANCH

Product Description

37, 42, 48M Concrete pump truck, popular more than 40 countries, Favorite brand in the world

1. ISUZU engine, 6WF1A, 265KW
2. 6X4 DRIVING
3. 37.6m output height
4. 120m3 /h output capacity
5. STEYR tech axle
6. Favorited Cabin

Our Services
Warranty, technical training, spare parts surpplying, Phone or mail support
Company Information
The first automobile anufacturer, has a history more than 45years, business expanded to Asia, Africa, south America and all over the world, More than 10000 units producing capacity, ISO 9001, TS16949, ISO14001, OHSMS18001 certificate
FAQ
FOB or CIF terms,

Q: Can u provide the ISO9001 certificate or some others related?
A: Yes. We have been exporting trucks for years. Rich experience for exporting to different countries, African market, Russia, South America, this help us better know have to handle with different certificates needed.We also have cooperated several times with the third party named TCI from UK. They can inspect the trucks and trailers producing and shipping after getting your authorization.

Q: How about warranty item?
A: We could support u original spare parts. And also email or telephone assist in the following days. If necessary, for large quantity ordered, our engineer could go for technical assist.

Q: How could I trust your company?
A: We are the official authority company by SINOTRUK & FAW Qingdao Automobile Company.

Model			HTC5281THB38X-4Z
Pumping system	Max. Theor. output	m3/h	120
	(/) Max. Theor. concrete output Pressure(high/low pssure)	MPa	8
	Rated working pssure	MPa	32
	(/) Pumping frequency(high/low pssure)	min-1	26
	Hopper capacity	L	600
	Filling height	mm	1600
	Hydraulic system type		Open loop
	Distribution valve		SS valve
	×Oil cylinder dia.×stroke	mm	Φ130×1900
	×Concrete cylinder dia.×stroke	mm	φ260×1900
	Hydraulic oil cooling		Air cooling
	Recommended concrete slump	cm	12~23
	Max. aggregate dimension	mm	40
Placing boom	Structure type		37X-4Z
	Placing depth	m	37
	Horizontal distance	m	34
	Placing depth	m	21
	Slewing angle		365°
	Pipe diameter	mm	125
	End hose length	mm	3000
	Min. height of opening placing boom	mm	8500
	(××)Outriggers span (front×rear×side)	mm	6200×7200×8120
Chassis and the whole machine	Chassis model		CYZ51Q
	Wheelbase	mm	4600+1350,4575+1400
	Engine type		6WF1A
	Engine power	kW/(r/min)	265/2200
	Oil tank cubage	L	400
	Tail gas exhaust standard		III
	Total weight	kg	29870
	(××) Overall dimensions	mm	12000×2490×3850
Others	Lubrication mode		Automatic lubrication
	Oil tank volume	L	400
	Control mode		+Manual+remote control
	Maximum water pssure	MPa	0.7
	Water tank volume	L	500
	Pipe cleaning mode		/Water cleaning/dry cleaning
