42/45m Mobile Concrete Pump Truck with Boom

42/45m Mobile Concrete Pump Truck with Boom

Our 42/45m concrete pump truck:
1.for concrete pumping
2.ISUZU Chassis,low oil consumption,great mobility;
3.ISO CE certified


Why would our clients choose FOCUS concrete pump truck?
1.large pumping capacity with high efficiency;
2.light-weighed and optimized design enables FOCUS concrete pump truck small occupation of ground area;
3.low oil consumption, economic engineered;
4.full hydraulic system guarantee stable pumping performance;


Features of FOCUS Portable/Mobile Concrete pump truck:
1. large pumping capacity with high efficiency;
2. light-weighed and optimized design enables FOCUS concrete pump truck small occupation of ground area;
3. low oil consumption, economic engineered;
Features of FOCUS Portable/Mobile Concrete pump truck:
1. large pumping capacity with high efficiency;
2. light-weighed and optimized design enables FOCUS concrete pump truck small occupation of ground area;
3. low oil consumption, economic engineered;
4. full hydraulic system guarantee stable pumping performance;

Our 42/45m Boom Portable Truck-mounted Concrete Pump Truck Main Parameters

Item	unit	HDT5340THB-42/4	HDT5380THB-45/5
outputintheory	m3/h	125	125
indexofthepumpcarrycapacity	Mpa.m3/h	586	586
theoreticpumpingpssure	Mpa	8.5	8.5
bucketvolume	L	700	700
heightoftopsurfaceofbucket	mm	1400	1400
modelofdistributionvalve		SValve	SValve
max.operationradius	m	38	40.7
max.operationheight	m	41.8	44.7
max.operationdepth	m	29	31.3
openheightofboom	mm	8600	8495
diameterofdeliverypipe	mm	125	125
lengthofhosepipe	m	4	3
rotaryrangeofboom		370°	365°
quantityofboom		4	5
rotaryangleofeachboom	°	92/180/180/240	91/180/180/180/270
wirelinecontroldistance	m	33	33
remotecontroldistance	m	200	200
max.speed	km/h	85	85
min.turnradius	mm	11900	11900
brakedistance	m	10	10
approachangle	°	16	16
departureangle	°	11	11
chassismodel		ISUZUCYH51Y	ISUZUCYH51Y
max.engineoutputpower	kw	287(1800r/min)	287(1800r/min)
max.engineoutputtorque	n.m	1863(1100r/min)	1863(1100r/min)
max.gradientability	%	37	35
fuelconsumption	L/100km	38	40
outdimension (LxWxH)	mm	13800x2490x3995	13100x2500x3900
totalweight	kg	34500	38000
