Warehouse Rack, Storage Rack, Pallet Rack, Drive in Rack

Warehouse Rack, Storage Rack, Pallet Rack, Drive In Rack

Our Storage pallet rack work with forklift passed CE and ISO9001, with the features of simply structure, easy operation and a wide range of access.
Storage pallet rack system structured with pallets and beams are most widely used. This kind of steel pallet rack is widely used together with forklifts, steel storage containers, steel pallets and storage boxes.


Structure of Storage pallet rack work with forklift:
Beams
Horizontal bracing
Diagonal bracing
Uprights
Screw, safe pins
Protector
Trays, pallets, or steel mesh plates


Determinant of Storage pallet rack work with forklift:
1. The weight of your goods (trays, steel containers / boxes are included)
2. The dimension of your goods together with pallets ( Length Width Height )
3. The maximum height of your forklift and the available height of your warehouse
4. The dimension of your forklift
5. The fork direction
6. The dimension of your warehouse
7. The path of the transportation


Contact information:
Casy: 0086-13851406693

Length	1500	1800	2000	2300	2500	2700	3000	3300
Beam Specification	Load/kg
80×50	3000	2300	1800	1500	1200	1000	800	700
100×50	4000	4000	3000	2400	2000	1750	1400	1100
120×50	4000	4000	4000	3500	3000	2500	2000	1800
140×50	4000	4000	4000	4000	4000	3800	3000	2500
