Drum capacity | 5.5m³ |
| Concrete output | 4m³. |
| Loading ratio | 76% |
Rotary drum | Discharge mouth height 1.8 meters.Level turn 290 ° (options) |
| Production capacity | 4 batches in an hour.16 cubic meters per hour |
| ENGINE | Yto 85kw or Yuchai 95KW. |
| transmission way | Full hydraulic drive.4 wheel drive and 2 turns.All the power comes from hydraulic oil, including walking 4X4. |
Climbing ability | 30% |
speed | Low speed 0-25 km/h, high speed 0-45 km/h. |
| CAB | Ultra wide deluxe cab.ROPStype. |
hydraulic system | Open feed, two gear pump participate in action. |
joystick | A four-way hydraulic pilot with an electric control button controls the bucket. |
| bucket | 650L, hydraulic gate. |
chute | Equipped with two removable shaft pins to increase the discharge length. |
| Water supply system | Self-priming hydraulic drive pump/electronic water flow monitor/high pssure washer (optional). |
| brake | inner wheel brake and the emergency brake operate on 4 wheels, enabling the small servo pump on the independent double-return road.Negative pssure type stop brake, the front bridge is equipped with inner hub. |
| Turn | Hydraulic steering, rear wheel steering. |
| tyre | 16/70-20 wire tires |
| power system | 24V |
| OIL TANK/water tank | 2 x210L water tank.Dieseltank: 125 litres.Hydraulic tank: 130 litres. |
weight | 7600KG |
| L*W*H | 7500MM*2700MM*3380MM |
wheelbase | 2.35M |
metering | Electronic weighing system (optional). |
