Un-Victor (Mrl III) Passenger Elevator

WHY XIZI
High quality: Heidenhain encoder, Premium magnetic steel thermostable up to 180 degree, accurate leveling, PM door operator, optional multi functions...
Energy Saving: as high as 40%
Space saving: smaller shaft size required;
Low noise: quiet brake, 5-10 (db)A noise reduced, perfect for residential
Xizi Produce all the core components by own factory (Machine, Controller, door operator); the components have better compatibility
Joint venture with Otis: advanced technology, management and quality control system


UN-VICTOR MRL Passenger elevatoris the first developed by XIZI Elevator with the concept of machine rooless. Compared with traditional elevator with machine room, the compact structure makes aclear advantage of construction. Since it saves room and greatly reduces construction cost, it is an ideal choice of developers and investors.

UN-VICTOR MRL
Main specification:
Capacity: ≤1000kg
Speed: 1.0m/s-1.75m/s
Machine: UNT09
Controller: U-Con L2000
Door operator: U-DF01 VVVF door operator
Car operation panel: U-CF100
Door protection: Infrared curtain
FUNCTION
Public Safety of passenger
1Light curtain
2ANS-Anti-Nusisance Car Call Protection
3Intelligent anti-nuisance function
4LNS-Lodad Non Stop
5LWS-Overload Protection
6Button anti-adhesion protection
7Door closing torque protection
8ELTU-Emergency light
9ALARB-Alarm Bell
10DTC-Door Time Protection Close
11DTC-Door Time Protection Open
12Door panels forced cloding upon gravity
13EFP-Emergency Fireman operation
14EFO Reservation
15Fire feedback
16Local leveling
17Fire feedback
18ARD-Automatic Rescue Device
19Earthquake operation
20Core closing anti-function (1.0-2.5m/s)
21Door opening prohibition outside door zone
Basic functions of elevator
1Floor display
2FCL-Full collective operation
3Dynamic display
4CBC-cancel error calls
5Autonmatic elimination of reverse command
6Door re-opening
7DHB-Door Hold Button
8Locking at main landing
9Braille button
10Time peak
11Hall arrival gong
12Car arrival gong
13Auxiliary operation panel
14Operation panel for handicapped
15Automatic return to main landing
16Machine room sound-proof and vibration-proof device
17Group Control
System safety
1Contact detection and protection on safety contactor
2Brake feedback&detection
3Independent dual brake
4Running time limiter
5Overspeed protection
6Low speed protection
7OHT-Drive overheat
8Two way monitoring door lock
9Safety circuit fault protection
10Main control CPU WDT protection
11HOP Checking
Basic structures
1frame-type box
2Elastic soundproof car body
3Car top spring damping
4installtion of beam-tyoe door operator
