Indoor, outdoor, 16-hr operation daily.
Horizontal span (m)
Step width (mm)
Upper landing horizontal distance (mm)
Tempered glass (10mm)
Balustrade height (mm)
Inner & outer decking
Hairline stainless steel
Hairline stainless steel
Stainless steel (anti-sliding)
Lighting under upper & lower landing pallets
Failure code indicator on control cabinet
Emergency stop button
Static electricity protection
Eliminate static electricity raised from running of the steps (pallets).
Static electricity protection of handrail
Eliminate static electricity raised from tunning of the handrail.
Emergency stop of button on entrance
Push the emergency stop button to stop the escalator (moving walk) against emergency raise.
Handrail entry safety protection
Protection against risk of the sundries being jammed into handrail entry.
Over speed protection
Protection against risk of speed being over 20% of rated speed.
Under speed protection
Protection against risk of speed being less than 20% of rated speed.
Unintentional reversal protection
Protection against risk of unintentional reversal of the direction of travel.
Phase failure protection
Protection against risk of phase failure.
Short circuit protection
Protection against risk of short circuit.
Protection against risk of motor continually over load.
Step (pallet) loss protection
It stops when it monitors the step (pallet) loss.
Step (pallet) sagging protection
Protection against risk of steps (pallets) being breakage and sagging.
Step (pallet) chains safety protection
Protection against risk of steps (pallets) chains being breakage of undue elongation.
Comb safety guard
Protection against risk of the sundries being trapped at the comb.
To provide voltage to inspect or maintain.
Machine room guard
One safety plate separates machine room from movable parts such as step to protect service personnel.
Emergency stop button on control cabinet
Push the emergency stop button to stop the escalator (moving walk) against emergency raise when inspection and maintaining.
Handrail speed- detection protection
When the step (pallets) brake distance is 1.2 times larger than the stipulated distance, it pvents it from start again.
Protection against risk of foreign objects being jammed into clearance between steps (pallets) and skirting.
Floor anti-start protection
It stops when the floor plate is removed or opened.
Main drive chains safety protection
Protection of risk of drive chains being breakage or undue elongation.
Brushes on skirting to enhance the passenger's safety.
Host brake detection
When it detects the release condition of the host brake, it pvents it from start before its release.
It pvents the passengers from crawling to external handrail.
It installs outer cover plate which is closed to handrail height. It pvents the passengers from accidental crawl, skid, and fall.
It pvents the passengers from entering into the area between wall and handrail, between two escalators (moving walk).
Protection baffle is set in the crossing of outer handrail edge and any obstacle.
When it exceeds 1.4 times of the speed; the steps (pallets) and handrail running direction is opposite to the indicated direction, auxiliary brake stops the escalator (moving walk).
