Vvvf Autostart Available Escalator

Please Note:If you are interested in our products, please kindly advise the following specifications, then price will be sent immediately.

1. Rise height
2. Inclination
3. Step width

If any special requirement, please let me know the details, thank you.



GRE20/30/50 Escalator

Features:

Advanced micro-computer control system
High strength truss structure
Classical driving system
Completed safety devices
Comply with national standard GB 16899-2011 and European standard EN115


Adanced technology:

Streamlined handrail system in stainless steel reflects noble styly of western Europe with its 180°arc end and black inlet.
Advanced control system and driving device, superior driving chain, excellent workmanship assures the safe, reliable and stable operation.
The safety protection functions as many as 21 items fully comply with national and European standard.
Automatic lubrication system lubricates all kinds of driving components, which prolongs products' operation lift greatly.
The application of VVVF drive (optional) makes escalator (moving walk) be a repsentation energy saving product. By checking the traffic flow timely by means of photo electrical sensor located at the entrance of escalator, achieving auto moving with great energy saved.
Micro-computer controlled system performs with rapid calculation speed, high reliable moving, and also with failure code fixed, easy to be maintained.
Drive device arranged vertically assures enough space and convinience fro maintenance.

GRE20 standard specification
Application	Indoor, outdoor, 16-hr operation daily			Balustrade height(mm)	900
Rise height(m)	≤6	≤10		Innder & Outer decking	Hairline stainless steel
Angle of inclination(°)	35	30		Skirting	Hairline stainless steel
Step width(mm)	600/800/1000			Step	Stainless steel
Horizontal steps	2/2	2/2 3/3		Landing plate	Stainless steel(anti-sliding)
Speed(m/s)	0.5			Illumination	Lighting under uper & lower landing steps
Main power	380V/50Hz/3P			Indicatior	Failure code indicator on control cabinet
Balustrade	Tempered glass(10mm)			Operation	Emergency stop button Key switch Inspection operation
Handril bracket	Stainless steel
Handril	Black
GRE20 escalator's maximum rise is up to 10 meters

GRE30 standard specification
Application	Indoor, outdoor, 16-hr operation daily			Balustrade height(mm)	900
Rise height(m)	≤16			Innder & Outer decking	Hairline stainless steel
Angle of inclination(°)	30			Skirting	Hairline stainless steel
Step width(mm)	600/800/1000			Step	Stainless steel
Horizontal steps	3/3			Landing plate	Stainless steel(anti-sliding)
Speed(m/s)	0.5			Illumination	Lighting under uper & lower landing steps
Main power	380V/50Hz/3P			Indicatior	Failure code indicator on control cabinet
Balustrade	Tempered glass(10mm)			Operation	Emergency stop button Key switch Inspection operation
Handril bracket	Stainless steel
Handril	Black
GRE30 escalator's maximum rise is up to 16 meters

GRE50 public transport escalator standard specification
Application	Indoor, outdoor, 20-hr operation daily			Balustrade height(mm)	1000
Rise height(m)	≤6	≤27		Innder & Outer decking	Hairline stainless steel
Angle of inclination(°)	35	30		Skirting	Hairline stainless steel
Step width(mm)	600/800/1000			Step	Stainless steel
Horizontal steps	2/2	2/2 3/3		Landing plate	Stainless steel(anti-sliding)
Speed(m/s)	0.5			Illumination	Lighting under uper & lower landing steps
Main power	380V/50Hz/3P			Indicatior	Failure code indicator on control cabinet
Balustrade	Stainless steel inclined balustrade; Tempered glass(10mm)			Operation	Emergency stop button Key switch Inspection operation
Handril bracket	Stainless steel
Handril	Black
GRE50 public transport escalator's maximum rise is up to 27 meters

Company Profile

Sicher Elevator has introduced 16 advanced production lines, including full-automatic flexible metal plate production line, medium thick metal plate production line, control system production line, robot welding production line and automatic spraying production line, etc. It owns a full set of modern NC machine equipment and detection equipment on key and safety components, so as to ensure the product quality.


Salvagnini production line - full automatic flexible metal plate production line
Switzerland Raskin NC Multi-station Turret Punch Press
Germany Wagner Automatic Spraying Production Line
Control System Production Line
Germany Beyeler Servo NC metal Plate Production Line
German Kuka Robot Welding Production Line
Escalator and Moving walk Production Line
Italy Prima Laser Cutting Equipment
Germany Beyeler NC Multi-station Machine Center
Profile Shot Blasting Production Line





Sicher Elevator Co., Ltd. is a specialized, collectivized transnational operation enterprise through investment, merger and stock restricting.

Sicher covers an area of 147,600 square meters, with overall floorage 170,000 square meters, owns manufacturing center, R&D center, customer service center, as well as a height108 meters elevator testing towerwith the running speed of up to8.0m/s. It also has introduced production facilities and inspecting equipments with world advanced levels from Germany, Italy and other countries to keep theproduction capacity 40,000 units as annual output, which is a large-scale and global market-oriented manufacturing enterprise for elevator, escalators and parking system equipments.

SRH Aufzuge GmbH, as a wholly owned overseas subsidiary in Germany.
A member of German Elevator Association
Outstanding strength of manufacture ability, R&D ability, service level
Service network across 46 coutries and regions all over the world, 93 affiliated agencies and 916 service points in China.
