Vvvf Control Safe Running Escalator for Light Duty

Note:If you are interested in our products, please kindly advise the following specifications, then price will be sent immediately.

1. Rise height
2. Inclination
3. Step width

If any special requirement, please let me know the details, thank you.

Contact infomation:
Jerry Hu
+86 571 56551375

www.sicher-elevator.com



GRE20/30/50 Escalator

Features:

Advanced micro-computer control system
High strength truss structure
Classical driving system
Completed safety devices
Comply with national standard GB 16899-2011 and European standard EN115

GRE20 standard specification
Application	Indoor, outdoor, 16-hr operation daily			Balustrade height(mm)	900
Rise height(m)	≤6	≤10		Innder & Outer decking	Hairline stainless steel
Angle of inclination(°)	35	30		Skirting	Hairline stainless steel
Step width(mm)	600/800/1000			Step	Stainless steel
Horizontal steps	2/2	2/2 3/3		Landing plate	Stainless steel(anti-sliding)
Speed(m/s)	0.5			Illumination	Lighting under uper & lower landing steps
Main power	380V/50Hz/3P			Indicatior	Failure code indicator on control cabinet
Balustrade	Tempered glass(10mm)			Operation	Emergency stop button Key switch Inspection operation
Handril bracket	Stainless steel
Handril	Black
GRE20 escalator's maximum rise is up to 10 meters

GRE30 standard specification
Application	Indoor, outdoor, 16-hr operation daily			Balustrade height(mm)	900
Rise height(m)	≤16			Innder & Outer decking	Hairline stainless steel
Angle of inclination(°)	30			Skirting	Hairline stainless steel
Step width(mm)	600/800/1000			Step	Stainless steel
Horizontal steps	3/3			Landing plate	Stainless steel(anti-sliding)
Speed(m/s)	0.5			Illumination	Lighting under uper & lower landing steps
Main power	380V/50Hz/3P			Indicatior	Failure code indicator on control cabinet
Balustrade	Tempered glass(10mm)			Operation	Emergency stop button Key switch Inspection operation
Handril bracket	Stainless steel
Handril	Black
GRE30 escalator's maximum rise is up to 16 meters

GRE50 public transport escalator standard specification
Application	Indoor, outdoor, 20-hr operation daily			Balustrade height(mm)	1000
Rise height(m)	≤6	≤27		Innder & Outer decking	Hairline stainless steel
Angle of inclination(°)	35	30		Skirting	Hairline stainless steel
Step width(mm)	600/800/1000			Step	Stainless steel
Horizontal steps	2/2	2/2 3/3		Landing plate	Stainless steel(anti-sliding)
Speed(m/s)	0.5			Illumination	Lighting under uper & lower landing steps
Main power	380V/50Hz/3P			Indicatior	Failure code indicator on control cabinet
Balustrade	Stainless steel inclined balustrade; Tempered glass(10mm)			Operation	Emergency stop button Key switch Inspection operation
Handril bracket	Stainless steel
Handril	Black
GRE50 public transport escalator's maximum rise is up to 27 meters

Adanced technology:

1) Streamlined handrail system in stainless steel reflects noble styly of western Europe with its 180°arc end and black inlet.
2) Advanced control system and driving device, superior driving chain, excellent workmanship assures the safe, reliable and stable operation.
3) The safety protection functions as many as 21 items fully comply with national and European standard.
Automatic lubrication system lubricates all kinds of driving components, which prolongs products' operation lift greatly.
4) The application of VVVF drive (optional) makes escalator (moving walk) be a repsentation energy saving product. By checking the traffic flow timely by means of photo electrical sensor located at the entrance of escalator, achieving auto moving with great energy saved.
5) Micro-computer controlled system performs with rapid calculation speed, high reliable moving, and also with failure code fixed, easy to be maintained.
6) Drive device arranged vertically assures enough space and convinience fro maintenance.
