| Installation Environment: | IndoorandOutdoor | |
| Layout | According to Construction plans | |
| TravelHeight | H≤20000mm | |
| Step width (mm) | 600, 800, 1000, 1200 | |
| ,Up-down horizontalstep | 2/2(35°), 3/3(30°) | |
| Angle of inclination | 35°, 30° | |
| Operating speed | 0.5m/s | |
| Start method | VVVF, VVVF+Autostart | |
| Step | Stainlesssteel, Aluminum(standardforoutdoor) | |
| Color | Natural color,Black | |
| Capacity (persons/h) | 4500,6700,9000 | |
| Step cordon | Yellow paint | |
| Driver Traction machine | Worm And Gear | |
| Motor protection level | IP 21,IP54 | |
| Power Supply | Motor Power: 380V±7%, 50Hz Three Phase Five Wire System Lighting Power: 220V, 50Hz, Single Phase | |
| Truss | Angle | |
| Installation length | Standard | |
| Truss process | Paint process(colour TK005),Hot-dip Galvanizing | |
| Handrail System | Chain friction wheel | |
| Handrail type | Vertical type,Apsaclinetype | |
| Handrail breast board | Temperedglass(10mm),verticaltotruss Hairline Stainless steel | |
| Handrail bracket material | 430 stainless steel hairline | |
| Handrail height | 900mm,1000mm(optional) | |
| Handrail Color | Black(optional: Red, Blue, Brown Green, Gray) | |
| Handrail drive (friction) | Roller Chain | |
| Inner and outer cover | 430 stainless steel(Indoor) , 304stainless steel(Outdoor) | |
| Skirting material | 430 stainless steel(Indoor) , 304stainless steel(Outdoor) | |
| Floor plate | 403 stainless steel grain type (indoor),304stainless steel(Outdoor) | |
| Comb plate | Aluminium alloy | |
| Energy Saving Function | VVVF, Auto Start-Stop, Skirt brush Runnning direction light |
