Contact Information :
| JB-TDA15L | |||
| Motor | Light weight high speed brushless hub motor | frame | 6061 aluminium alloy. |
| 24month warranty | Tyres | * Tyre:KENDA 27.5×1.95 With Reflective Stripe | |
| Brushless | Rim | AlloyDouble Wall | |
| Front fork | TGS Suspension fork | ||
| 36V/250WBafang | Front brake | :Auriga E-Comp Hydraulic disc brake | |
| Battery | 36V/10.4AH SANYO Battery 0.26*40 | Rear brake | :Auriga E-Comp Hydraulic disc brake |
| Speed gears | Shimano 7Speed Gears | ||
| 24 month quality warranty | Rear derailleur | SHIMANO Tourney +guider(Acera available) | |
| PAS | Intelligentpedal assistant system +5 Levels 8FUN LCDDisplay, Power On/Off Switch | Handlebar /grip | ZOOM Brand |
| Controller | intelligent bruhsless. 12 month warranty | Stem | ZOOM Brand,Foldable Stem |
| Charger | AC 100V -240Vsmart charger | Brake lever | Tektro Brand |
| Charging time: 4to 6hours 12 month warranty | Chain | Rust resistant chain. | |
| Throttle | Can use Throttle with Pas or Pas only | Chain wheel | 42-44-48-52T ,al alloy crank. |
| Performance | Mudguard | PVC | |
| Max speed | 25 to 38km/h | Rear rack | NA |
| Range | 40-45 kms | Saddle | VELO Saddle,alloy Suspension |
| Seat post | Foldable HS-6006 | ||
| Max load | 120 kgs | Pedal | Wellgo |
| Net weight | 25.0kgs | Lighting | LED Headlight And Taillight |
| N.W /G. W | 27 kgs /30 kgs | Normal paint color | Any color is available |
| container load | 80 pcs/20GP,170 pcs/ 40HQ | Normal Packing size | 155X26X74CM special for exporting |
BATTERY
Standard Lithium-ion 36V10.4Ah with upgrade to maximum 36V11.6Ah Samsung.
Autonomy 30-50Km depending on the rider, road climbing degree and PAS selected.
Available cells brandPANASONICorSAMSUNG.
MOTOR
-Last generation Bafang MAX mid drive system
-Integrated motor plug, for afast and easy replacement of the complete rear motor wheel in case of necessity.
- Gear sensor available
DISPLAY
Last generation display LCD
- 9levels of PAS to be selected
- Speed available at request
- Battery indicator.
- Speedometer.
SHIMANO gear and disc brake
Model ACERA 9gears.
Derailleur protector included.
On request all the series Shimano are available.
Front and Rear light
