Detailed Description
This type lifeboat can assure your life with gravity luffing arm type davit or platform davit to raise and load.It is suitable in, for example the ocean boat, it is high Fire-resistant.
Material:
Hull: Glassfiber reinforced polyester
Buoyancy: The space between the outer hull and the inner section are buoyancy tanks and filled with polyurethane hardform
| Model | Dimension
(Meters) | Person
(Max.) | Hook Distance
(Meters) | Total Height
(Meters) | Total Weight
(Kg) |
| MM50C-I | 5.00 X 2.20 X 1.20 | 26 | 4.70 | 3.10 | 4253 |
| MM50F-I | 4547 |
| MM50C-II | 5.00 X 2.20 X 1.20 | 27 | 4.60 | 3.00 | 4326 |
| MM50F-II | 4646 |
| MM57C | 5.00 X 2.20 X 1.20 | 25 | 5.30 | 3.00 | 4368 |
| MM57F | 4768 |
| MM65C-I | 6.50 X 2.30 X 1.20 | 36 | 6.10 | 3.10 | 5956 |
| MM65F-I | 6251 |
| MM65C-II | 6.50 X 2.32 X 1.15 | 36 | 6.10 | 3.10 | 5815 |
| MM65F-II | 6130 |
| MM70C | 7.00 X 2.70 X 1.10 | 51 | 6.60 | 3.10 | 7111 |
| MM70F | 7425 |
| MM58C | 5.80 X 2.85 X 1.20 | 52 | 5.40 | 3.10 | 6925 |
| MM58F | 7265 |
| MM80C | 8.00 X 2.85 X 1.20 | 72 | 7.60 | 3.10 | 9260 |
| MM80F | 9598 |
| MM85C | 8.50 X 3.10 X 1.22 | 85 | 8.10 | 3.10 | 11137 |
| MM85F | 11468 |
| MM93C | 9.30 X 3.45 X 1.30 | 106 | 8.90 | 3.35 | 13810 |
| MM93F | 14220 |
| MM102C | 10.28 X 3.50 X 1.30 | 130 | 8.95 | 3.35 | 15375 |
| MM102F | 15775 |
| MM117C | 11.70 X 3.55 X 1.30 | 150 | 11.30 | 3.40 | 18190 |
| MM117F | 18600 |
Product Image
