Why use compactor garbage truck?
1. Reverse mechanism: the reverse mechanism of assembly with garbage can (or garbage bucket); It is more convenient to collect and dump garbage.
2. The method of garbage collection is simple: to change the dirty old appearance of garbage cans in city streets and eliminate secondary pollution.
3. The compssion ratio is high and the load is large: the maximum crushing pssure is 12 tons, and the load amount is equivalent to two and a half times that of the non-compssed garbage.
4. homework automation: the imported computer control system, all fills discharge operation in one operator need driver, not only reduce the labor intensity of sanitation workers, and greatly improve the working environment.
5. Good economy: when special equipment works, the computer control system automatically controls the throttle.
6. Double insurance system: the operating system has dual functions of computer control and manual control, which greatly guarantees and increases the utilization rate of vehicles.
7. Sealing performance: no garbage leakage can be realized in the process of collection and transportation.
Specifications:
| cabin | Driving type 4x2 | ||
| 2080 Standard cab, with threeseats,with A/C. Left Hand Driven. 70°hydraulically tillable to the front as attached photo for ref. | |||
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 7300x2450x2800 | |
| Wheel base (mm) | 3300 | ||
| Wheel track (front/rear) (mm) | 1798/1764 | ||
| Approach/Departure angle(°) | 27/20 | ||
| Weight in KGS | Tare Weight | 6400 | |
| Loading Capacity | 5000 | ||
| Front axles loading capacity | 1x3200 | ||
| Rear axles loading capacity | 1x8200 | ||
| Max. driving speed(km/h) | 90 | ||
| Engine | Brand | YUCHAI | |
| Model | YC4E140-20 | ||
| Type | 4-stroke direct injection , 4-cylinder in-line with water cooling, turbo-charging and inter-cooling | ||
| Horse Power(HP) | 140 HP | ||
| Emission standard | Euro | ||
| Gearbox | WLY6T51 , 6 forwards &1 reverse | ||
| Clutch | Diaphragm spring clutch | ||
| Steering Gear | Power steering | ||
| Fuel tank (L) | 130 L | ||
| Tire | 7.50R12-14 All radial tires with one spare, 7 pieces | ||
| Compssion garbage box body system | |||
| BodyVolume | 4 CBM | ||
| Cycle Time of Filling(S) | ≤40 | ||
| Lifting Time of Filler(S) | 8-10 | ||
| Time of Discharging | ≤60 | ||
| Working Pressure(MPA) | 16 | ||
| Composed by hermetic garbage tank, hydraulic system, operation system. The entire truck is hermetic, can automatically compss and dump the garbage .and the sewage generated in the process of the compssion all go into the sewage tank. | |||
The garbage compssion truck consists of the sealed garbage box, hydraulic system and operating system. Compssion car vehicle is fully sealed type, compssion, to dump all, compssion in the process of sewage into the water, more thoroughly solved the compssed secondary pollution problem in the process of vehicle transportation, key parts imported parts, high pssure, good sealing, convenient operation, safety, etc.
Our Product Advantages
(1) Products Quality Certification SGS CCC ISO
(2) Perfect after-sale service
(3) Customized products available with us
(4) Export to more than 30 countries and regions
