ProductIntroduction ofCcg Mining Explosion-Proof Diesel Locomotives
Ccg Mining Explosion-Proof Diesel Locomotives is a kind of driven, the vehicle with proof performance for co
ntaining flammable gas and coal dust and other dangerous places, traction, transport of mining locomotives, traction battery and then following the hydraulic transmission of a utility model traction. Mine explosion-proof drum & rail locomotive diesel engine series, is in line with the ideal of coal mine production safety transportation equipment. It is reaso
nable structure, compact, energy saving, high efficiency, easy operation and maintenance, f
rame lines motor vehicle, motorcycle batteries, compared does not need to set up traction power, do not need AC power and charging equipment.
MainCharacteristics ofCcg Mining Explosion-Proof Diesel Locomotives
1.Double-endedlocomotivedriving,easyoperationandpassengers,andbetteroutlook;
2.Bodyshort,maintainingroadwayturningradiusbytheflexibilityandstability;
3.Electricstarter,controlroomsforsoundprocessing,noisereduction;
4.By(European)im
porttheessenceofdevice,thesecondexhaustgastreatment,tofurtherreduceemissions.
TechnicalParameters ofCcg Mining Explosion-Proof Diesel Locomotives
Model(basic
parameter)
Item | CCG3.0/600J(B) | CCG5.0/600J(B) | CCG8.0/600J |
| MatchedPowerModel | ZS1115FB | YH1125SFB | YH4108DFB(A) |
| Dimension(L*W*H)mm | 2400*920(1000)*1600 | 3020*1000(1098)*1600 | 3700*1100*1600 |
| Weightkg | 3000 | 5000 | 8000 |
GreatestTraction
ForceKN | 4.5 | 7.5 | 12 |
| PullingTonnageT | 15 | 22 | 35 |
| Gaugemm | 600(madetoorder) |
| Wheelbasemm | 706(712) | 880(860) | 980 |
| GreatestSpeedkm/h | 15+1 | 17+1 | 20+2 |
| DieselEnginePower(kw)/RotatingSpeed(r/min) | 11/2200 | 14.7/2200 | 52/2400 |
| SmallestRailwayOrbitm | 5 | 6 | 7 |
| GreatestBrakingForceN | 5000 | 8000 | 12800 |
| TractionHeightmm | 270320 | 320430 | 320430 |
| BrakingDistancem | 40 |
| HeightAboveGroundmm | 80 | 125 | 125 |
| BrakingMode | footandmachinecontrol | airandhandwheelcontrol |
| ExhaustQuality | CO≤0.1%NOX≤0.08% |
Pictures ofCcg Mining Explosion-Proof Diesel Locomotives
