| locomotive Model No. specifications | CAY8/6GP | CAY8/7GP | CAY8/9GP |
| Adhesive / total weight (t) | 8 | 8 | 8 |
| Track gauge (mm) | 600 | 762 | 900 |
| Wheelbase (mm) | 1100 | 1100 | 1100 |
| Wheel diameter over tread | 680 | 680 | 680 |
| Coupler height over Steel rail (mm) | 320/430 | 320/430 | 320/430 |
| Min Curve radius (m) | 7 | 7 | 7 |
| Battery volt rating (V) | 132(440Ah) | 140(440Ah) | 192(440Ah) |
| Braking method | Mechanical and electrical | Mechanical and electrical | Mechanical and electrical |
| Max tractive effort (KN) | 22 | 22 | 22 |
| Max speed (km/h) | 20 | 20 | 20 |
| Rated speed per hour (km/h) | 10 | 10 | 10 |
| Power of traction Motor (KW) | 2*22 | 2*22 | 2*22 |
| Transmission | Single level Spur gearing | Single level Spur gearing | Single level Spur gearing |
| Controller | AC frequency conversion | AC frequency conversion | AC frequency conversion |
| Over all dimensions (mm) | 4460*1060*1590 | 4400*1340*1590 | 4460*1340*1590 |
| Service & Application | Mucking in mining & tunneling | Mucking in mining & tunneling | Mucking in mining & tunneling |
