| Dimension | |
| Overall length (mm) | 8500 |
| Overall width (mm) | 2400 |
| Overall height (mm) | 3100 |
| Wheel base (mm) | 4000 |
| Wheel track front/rear (mm) | 1910/1800 |
| Front/rear overhang (mm) | 2000/2500 |
| Performance | |
| Grade ability (%) | ≥25 |
| Min Turning Diameter (m) | 18 |
| Max Speed (km/h) | 100 |
| Max stopping distance (m) | <10(full loading 30km/h) |
| Max distance(km) | 350km |
| Mass | |
| Complete bus mass (kg) | 7890 |
| Max loading mass (kg) | 11010 |
| Passage | 15-32/57 |
| Exhaust standard | ZERO emission |
| Motor | |
| Model Type | D/C MOTOR 78KW |
| Rated power (kw/ps) | 78KW |
| Max torque (N.m/rpm) | 660/1300-1500 |
| Chassis | |
| Steering | Integral hydraulic power steering |
| Clutch | Single, dry |
| Transmission | Five speed |
| Suspension system | Multi-leaf spring |
| Brake system | Storage spring exhaust brake |
| Tire | 8.25R20/8.25R20 |
| Battery type | Lithium battery 320v 400ah |
