| TECHNICAL DATA |
| Length/Width/Height(mm) | 6745x2275x2980 |
| Interior height (mm) | 1850 |
| Engine model | YUCHAI diesel engine YC4D130-20 (Euro-2)/ YC4FA130-30 |
| Engine type | Front mounted, 4 cylinders in-line, 4 stroke, turbo-charged, water cooled system |
| Max. power/ rotating speed (kw/ r/ min) |
95/2200 |
| Max. torque/ rotating speed (N.m/r/min) | 340/1100-1500 |
| Displacement(L) | 2982 |
| Chassis model | Full chassis with Electrophoresis Coating |
| Top speed (km/h) | 125 |
| Axle distance (mm) | 4200 |
| Wheel track (front/rear) (mm) |
1860/1580 |
| Brake distance (v=30km/h fully loaded) | <10m |
| Fuel tank volume (L) | 90 |
| Fuel consumption (on certain condition) | ≤8.5 |
| Gross weight/ Curb weight (kg) | 7300/4780 |
| Clutch | Single, dry, diaphragm type |
| Transmission | 5 forwards manual |
| Rear axle | Integral axle housing, single reduction final drive |
| Front axle | Ends fist, I section |
| Suspension system | Leaf spring |
| Steering system | Integral power steering, LHD |
| Braking system | Dual circuit air brake, drier, energy storage spring chamber blue added |
| Tire | 215/75R17.5 Tubeless tyre |
| Body type | The body of bus is welded by SS400 rectangular steel tube. side panels are stretched high-quality galvanized panels. The bottom of the chassis is specially treated with anti-corrosion glue. The whole bus is heat insulation |
| Interior trim | Luxury interior trim,d safety ceiling window, luxury rear-view mirror,concaved floor with wear-resisting vinyl |
| Door and door pump | Auto flxed passenger door |
| Window | Pull-push window |
| Seat and accessories | 23 seats common seats, safety belts |
| Video and Audio | USB MP3 player+ radio, MonITOR CAMARA |
| Lamp | Integral front lamp, front ceiling height lamp, side mark lamp,high-level brake lamp |
| Service equipment | E-clock, engine compartment automatic fire extinguisher, 8KG fire extinguisher, vehicle tools, 4 safety hammers. |
