We're one specialist truck refitting and semi trailer manufacturer in China, we could supply various special purpose trucks and semi trailers. Our products are always popular in China several years.
From 2005, China allow exporting completed truck and semitrailer. We established overseas department that year and exported more than 30 counties promptly. Our products got almost clients' love and admiration. We appciate our clients' fully trust to us, and remember the responsibility every moment.
There're too much processes need to do during producing, we never dare to reduce anyone. And we never dare to reduce any material although it's expensive. All of these only for ensure the high quality and excellent performance.
Respectful,Faithful,Studious,Innovative .Our progress never could leave your supporting. Warmly welcome your coming!
Why use compactor garbage truck?
1. Reverse mechanism: the reverse mechanism of assembly with garbage can (or garbage bucket); It is more convenient to collect and dump garbage.
2. The method of garbage collection is simple: to change the dirty old appearance of garbage cans in city streets and eliminate secondary pollution.
3. The compssion ratio is high and the load is large: the maximum crushing pssure is 12 tons, and the load amount is equivalent to two and a half times that of the non-compssed garbage.
4. homework automation: the imported computer control system, all fills discharge operation in one operator need driver, not only reduce the labor intensity of sanitation workers, and greatly improve the working environment.
5. Good economy: when special equipment works, the computer control system automatically controls the throttle.
6. Double insurance system: the operating system has dual functions of computer control and manual control, which greatly guarantees and increases the utilization rate of vehicles.
7. Sealing performance: no garbage leakage can be realized in the process of collection and transportation.
6x4 18/20/22m3
| Model | HTC5251ZYSA |
| Chassis Model | ZZ1257N3847C |
| ZZ1257M3847C | |
| Overall Dimensions(L×W×H) (mm) | 10695X2500x3290(3490) |
| Pressure of Hydraulic System (MPa) | 20 |
| Kerb Mass(kg) | 14670/14870 |
| Loading Mass(kg) | 10200/10000 |
| Gross Vehicle Weight (kg) | 25000 |
| Max. Speed (kg/h) | 90 |
| Engine Model | WD615 |
| Engine Output (KW/r/min) | 247/2200 |
| Body Volume ( m3) | 20/22 |
| Filler Volume ( m3) | 2.5 |
| Cycle Time of Filling (s) | ≤25 |
| Lifting Time of Filler(s) | 8-10 |
| Time of Discharging(s) | ≤40 |
| Front / Rear Sewage Tank volume (L) | 250+150 |
| Max.Compssion Force(kg) | >35000 |
(1) Products Quality Certification SGS CCC ISO
(2) Perfect after-sale service
(3) Customized products available with us
(4) Export to more than 30 countries and regions
