| TECHNICAL SPECIFICATION | |
| Overall Dimensions | |
| Length (mm) | 7480 |
| Width (mm) | 2240 |
| Height (mm) | 3020(withA/C) |
| Interior height (mm) | 1980 |
| Wheel base (mm) | 3800 |
| Front/Rear Overhang (mm) | 1835/1586 |
| Min. Ground clearance(mm) | 200 |
| Approach/Departure Angle(o) | 11/13 |
| Vehicle structure | Half loaded |
| Brake distance (v=30km/h) | ≤10 |
| Kerb weight (kg) | 5000 |
| Front /Rear Axle (kg) | 2700/5000 |
| Max. Total Mass(kg) | 7400 |
| Max. Speed (km/h) | 125 |
| Max. Grade ability (%) | 30 |
| Min. turning diameter (m) | 10 |
| Fuel Tank Capacity (L) | 150 |
| Luggage compartment(m3) | 4.5 |
| Engine | |
| Arrangement of Engine | water cooling, charged air coolant, turbo charged |
| Model | YC4D130-20, YC4D130-30 |
| Displacement (cc) | 4212 |
| Position | Front mounted |
| Max. Output (kw) | 96kw, 131hp |
| Max. Torque (N.m/rpm) | 380/1700-2000 |
| Type of Fuel | Diesel |
| Emission Standard | Euro II, III |
| Chassis | |
| Anti-corrosion system | Full chassis with Electrophoresis Coating |
| Clutch | Strong quality and advanced durable clutch |
| Gearbox | US FAST 5Speed Manual |
| Suspension system | spring suspension |
| Steering system | Integral power steering |
| Braking system | Dual-circuit air braking Air release parking |
| Tire | 7.50R16steel wire tire or tubeless tire |
| Electric system | 24v Single wire, Minus earth |
| Starter | 24V, electromagnetic operation |
| Battery/Alternator | 2 150A alternators |
| Body | |
| Body structure | Semi-integral body Pre-stress stretched panel skin Full metal body |
| Anti-corrosion system | Full body with Electrophoresis Coating |
| Inner trimming | Integral A/C channel A/C outlet with reading light Hang-type curtain Deluxe inside luggage rack |
| Door and door pump | Front pneumatic out-swing single door |
| Windows | Upper fix and lower sliding window |
| Roof hatch | one |
| Seat | 30seats,all seats with seat belt |
| Air-conditioning system | Powerfulroof mounted A/C |
| Defrosting system | Natural wind defrosting system |
| Audio and Visual system | Mp3 USB radio |
| Rear view system | Luxury Rabbit ear rear view mirror |
| Lamp | Integral head lamp LED tail lamp LED LED interior lamp |
| Others | Tool box Emergency hammers Fire extinguishers Fire extinguisher bomb Dark Grey side window |
