Shaolin LHD/Rhd Front/Rear Engine Shuttle Bus/Tourist Mini Bus

Shaolin LHD/Rhd Front/Rear Engine Shuttle Bus/Tourist Mini BusWheelbase: 3300mmMax. Speed: 100km/HRated-Power: 85kwControl Systems: Flexible ShaftOil Tank Capacity: 90LTotal Mass: 5700kgMax Seats Capacity: 23+1 SeatsGearbox: 5Speed- ManualTyre: 7.00-16Specification: 5995*2240*3000mm

ITEM		SLG6602C4E RHD/LHD
()DIMENSION	()LENGTH×()WIDTH×()HEIGHT(MM)	5995×2240×3000
	()Tread F(MM)	1750
	()Tread R(MM)	1586
	()WHEELbase (MM)	3300
()WEIGHT	()TOTAL MASS (KG)	5700
()PERFORMANCE	()MIN. VEHICLE TURNING CIRCLE (M)	11
	()MAX. SPEED (KM/H)	100
	(/)ANGLE (APP/DEP)	13/10
()Max SEATS CAPACITY		23+1 seats
()frameWORK		()STRAIGHT BEAM
()ENGINE	()MODEL	EURO2 YC4F115-20 CUMMINS EQB125-20 EURO 3YC4F115-30
	()TYPE	(4)4 CYLINDER IN-LINE
	()RATED-POWER (KW/R/MIN)	85KW
	()MAX. TORQUE (N.M)	300
	()EMISSION STANDARD	(II)EURO 2/(III)EURO3
	()FUEL TYPE	()DIESEL
()CLUTCH	()TYPE	()SINGLE PLATE DRY CLUCH
	()CLUTCH BOOST	WITHPUMP
TRANSMISSION	Gearbox	5 SPEED- MANUAL
	ConTROL SYSTEMS	FLEXIBLESHAFT
FRONT AXLE		2.3T
REAR AXLE		5T
BRAKING SYSTEM	STEERING	POWER STEERING
	SERVICE BRAKE	DUAL-CIRCUIT AIR BRAKING SYSTEM
	PARKING BRAKE	Diaphragm spring brake
	F/R BRAKING DIA.	Ф310
	F/R BRAKING SHOE Width	120/150
SUSPENSION STYLE		MULTIPLE-LEAF SPRING
TYRE		7.00-16
OIL TANK CAPACITY		90L

-------------------
