Traction type | 6X4 | |||
Driving type | Left Hand Driving | |||
Overall Dimension(LxWxH) | 7356x2496x3170 | |||
Wheel base(mm) | 3625+1350mm | |||
Curb weight(kg) | 12000 | |||
Max towed mass(kg) | 13000 | |||
Engine Steyr technology, made in China | WD615.62 | Diesel,4-stokeDirectinjection,6-cylinderin Line,radiator,turbo-charging | ||
Displacement(L) | 9.726 | |||
Bore X stroke (mm) | 126mm/130mm | |||
Max power(kw/rpm) | 270/220kw | |||
Max torque(Nm/rpm) | 1160Nm@1100-1600/rpm | |||
Emission | EUROII | |||
Fuel tanker(L) | 300LAluminum fuel tank | |||
Approaching/Departure angle() | 19/29 | |||
Clutch | Model | 430springtype | ||
Gearbox | Brand | Fuller (Fast) | ||
Model | HW15710 | |||
Steering system | Model | ZF8118hydraulic steering with power assistance | ||
frame | 865/317 8+8 | |||
Rear axle | AC16,doublereductiondrivingaxle, Ration:4.7 | |||
Tyre | 11.00R20 | |||
Number of tyre | 10+1 spare | |||
Suspension | Leaf spring type | |||
Front/rear: 9/12 | ||||
Color | optional | |||
Electrical | Battery | 2x12V/135Ah | ||
Generator | 28V-35A | |||
Starter | 5.4Kw/24V | |||
Cabin | HW70,shortflat roof, two seats, A/C. | |||
