New Co
ndition 4X2 FAW 5, 000L Water Tank Truck,tanker
New Co
ndition 4X2 Faw 5, 000L Water Truck
We're one specialist truck refitting and semi trailer manufacturer in China, we could supply various special purpose trucks and semi trailers. Our products are always popular in China several years.
From 2005, China allow exporting completed truck and semitrailer. We established overseas department that year and exported more than 30 counties prom
ptly. Our products got almost clients' love and admiration. We appciate our clients' fully trust to us, and remember the respo
nsibility every moment.
There're too much processes need to do during producing, we never dare to reduce anyone. And we never dare to reduce any material although it's expensive. All of these o
nly for ensure the high quality and excellent performance.
Respectful,Faithful,Studious,Innovative .Our progress never could leave your supporting. Warmly welcome your coming!
We can supply various Truck from 5 tons to 40 tons. Sprinkler, Spray Water Truck, Lorry, Van Truck, Wagon Truck, Cargo Truck, Oil Tank Truck, Garbage Truck, cemenet tank truck and so on.
Type: CA1073
Cabin: Tiger V
Engine Model: CA498E3-12
Emission standard: Euro 2
Power (KW): 120HP
Clutch model: 350mm, single plate, dry, diaphragm
Gearbox Model: 5-35 transmission
Rear Axle: 1085 axle
Rear Axle speed ratio: 5.286
Wheel & tire: 7.00R16, Model 14Ply Rating
Axle ba
se: 3270
Fuel Tank: 180L
Mass
Parameter Curb weight (kg): 4200
Gross truck weight:9000
Max. Loaded weight: 5000
Capacity of tank: 5 m3
Dimension of tank: 3500
x2100X1350mm
Overall dimension: 6060
x2500X2950mm
With front spray, rear sprinkle, hydraulic monitor.
Fuel Tank Truck, Fuel Truck, Refuel Truck, Tank Truck, Tanker Trucks, Oil Tank Truck, Tanker, Heavy Truck, Oil Tanker, Truck, Tank,
Q: How can we trust your company?
A: We are the official authority company by FAW Qingdao Automobile Company. And we are registered in the Commercial Department of China, with the whole qualification for exporting, you would feel relax and safe to do business with us.
Q: Can u provide the ISO9001 certificate or some others related?
A: Yes. We have been exporting trucks for years. Rich experience for exporting to different countries, African market, Russia, South America, this help us better know have to handle with different certificates needed.
Q: How a
bout warranty item?
A: We could support u original spare parts. And also email or telephone assist in the following days. If necessary, for large quantity ordered, our engineer could go for technical assist.
Water tank truck, water truck, water tanker truck, Fuel Tank Truck, Fuel Truck, Refuel Truck, Tank Truck, Tanker Trucks, Oil Tank Truck, Tanker, Heavy Truck, Oil Tanker, Truck, Tank,
| Brand | FAW |
| Driving | 4x2 |
| Colour | white, blue, red, yellow, green |
| Cabin | Tiger V |
| Steering | LHD/ RHD |
BRAND & MODE | FAW CA5073GYS |
| Load Parameters |
| G. V. W. (kg) | 9000 |
| Curb weight, toal (kg) | 4255 |
| Loading capacity (kg) | 5050 |
| Drive form | 4X2 |
| Max. speed KM/h | 90KM/h |
| Front axle capacity(KG) | 4000 |
| Rear axle capacity (KG) | 6000 |
| Leaf spring | 3/3+2 |
| Appr/Dep.:(°) | 19/20 |
| Dimension Parameters |
| Dimension(mm) (L*W*H) | 6230x2496X3035 |
| Water box | Dimension(L*W*H) | 3600x2100X1100 |
| Volume | 5.2m3 |
| Sprinkler width | |
| Wheel base(mm) | 3500 |
| Wheel trace(mm) | 1950, 1800 |
| Configuration Parameters |
| Cabin | Cabin type | |
| Seating capacity | 2 |
| Engine | Brand&Model | CA498E3-12 |
| Max. power | 120HP |
| Max.output torque | |
| Displacement(ml) | 3168 |
| Combustion types | Diesel |
| Gearbox | Brand&Model | CA5-35B |
| Emission standard | EURO 2 |
