80 Ton 4 Axle Lowbed Semi Truck Trailer

80 ton 4 axle lowbed semi truck trailer





Basic info

payload	60 T
Size	13000mm*3000mm*1400mm
Main beam	automatic welding with Q235 Bsteel ,thickness of 16/18/10 mm for the main beam
Side beam	automatic whelding I shape side beam
Cross member	Q235 B steel
Floor	5 mm checked steel
Side wall	without
Front board	without
Axle	Fuwa or optional. 13 ton *3 pcs
Suspension	Mechanical suspension
ladder	spring ladder
Tire	12.00R20 or optional 12 pcs
Kingpin	3.5 or 2.0
Landing gear	JOST C200
Braking system	WABCO braking valve
ABS	Optional
Painting	anticorrosive prime 1time ,final paint 2times
Accessories	tool box, side fence ,rear fence ,tire rack etc
Date of delivery	15-30 days after the deposit

Description

Axles adopt the amazing quality axles which is produced by famous producers, strong and stable . high performance to ensure the transportation safety of the box truck cargo trailer

Suspension of the truck cargo trailer is high quality ones with better performance on bad road transportation to protect the main beam and the axles.

12R22.5 trailer tires comes from the good brand like linglong, chengshan, double corn etc. Is able to work in hard conditions like the high temperature, cold conditions, or the dessert .

The steel of the cargo box adopt the high strength ones strictly controlled by the purchasing manger. And highly controlled by the producing manger while produced .





Reference drawing






Our service

(1) The trailer must striectly tested before the shippment to guarantee the customer's profit

(2) 1year warranty without man-made broken

(3) 24 online solving all the questions about the technical or othere

(4) English, French, Spainsh support with special servers .

(5) Spare parts are available all the time

(6) Regular follow-up to guarantee the trailer in good condition .
