 Tare Weight | about 8.3T |
| Dimension | 13000mm*2490mm*2860mm(Outerside)
12800*2300*1800mm |
| Axle | 13 T/16T, FUWA /BPW /Huajing Brand |
| Rim | 9.00-22.5 |
| Tire | 12.00R22.5/ 315 80R22.5 |
| King pin | JOST brand 2.0 or 3.5inch bolts type or Welding type |
| Support leg | JOST brand D200T orChinabrand 28Tons (Double speed) |
| Main beam | Height:500mm, upper plate is14mm, middle plate is8mm,
down plate is16mm; Material is Q345B Steel . |
| Side beam | 16mmor18mmchannel steel (Material is Q235steel). |
| Side Wall | 600mm-1800mm,the open door can be choose freely. |
| Brake chamber | WABCORE6relayvalve;T30/30+T30Springbrakechamber(TKLbrand); Two pieces of 45Lairtanks |
| ABS | Optional |
| Twist Locks | Four ,Eight or Twelve pieces (Lifting type or Twist Screw Type) ,optional |
| Valve | WABCO valve |
| Light | LED light |
| Voltage | 24V |
| Receptacle | 7 ways (7 wire harness) |
| Tool box | 1m × 0.5m × 0.5m (The tool box contains 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar. Its size can be tailored to suit your needs.) |
| Semi Trailer Surface Coating | Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats. |
| Shipping terms | By Bulk cargo carrier,RORO or 40'HQ containe |
Wuhan Yueruixiang Technology Co., Ltd is a professio
nal supplier of co
nstruction machinery and agriculture machinery, We are located in Wuhan City, Hubei province, China.
Our main products includes Co
nstruction machinery: Wheel loader, skid steer loader, Forklift, road roller, bulldozer, motor grader, excavator, plate compactor, rammer, co
ncrete cutter, ect,
And Agriculture machinery: Tractors and farming implements(backhoe, front end loader, wood chipper, rotary riller, lawn mower, plough, disc harrow, planter, ect) which wins the high approval in European, South and North America, Africa, Middle East and Asia due to our high quality and exceptio
nal after-sale service. The reliable quality source from the strict quality co
ntrol system.
At psent, some of products have passsed CE certification and ISO9001 quality system and in recent years the company has introduced advanced sequence equipment and technology from America, Germany, which assure the level of technique and measure of detect of the company to reach the internatio
nal advanced level and form the benigh cycle innovation system of researching, producting, sale and developing.
Welcome to co
ntact with us at any time.
