| Gross Weight | Approx. 5.5 tons or 3.2 tons |
| Dimension(mm) | 12450 × 2490 × 1557 (3 or 2 axles) 40FT7160 × 2490 × 1557 (2 axles) 20FT |
| Loading Capacity (Ton) | ≤ 45 T (40FT) ≤ 30T (20FT) |
| AXLES | 13 T /PER , FUWA Brand, BPW Brand, or Huajing Brand |
| Tire | 12.00R22.5 or 315/80R22.5Chinese Brand or according to customer requirements |
| Rim | 9.00-22.5 Chinese Brand |
| Suspension | Mechanical suspension (German or American type)Or Air suspension (Chinese brand or BPW brand ) |
| Spring Leaf | 90(W)mm×13(Thickness)mm×10 Layers or 100mm×12mm×12 layers |
| King Pin | JOST Brand 2.0 or 3.5inch (bolted or welded) |
| Landing Gear | JOST Brand D200T or Chinese Brand 28Tons (Double-speed) |
| Main Beam | Height: 500mm Upper plate: 14mm Middle Plate: 8mmBottom Plate is 16mm; Material: Q345B Steel |
| Side Beam | 16mm or 18mm steel channel (Material: Q235steel ). |
| Brake Chamber | WABCO RE 6 relay valve; T30/30+T30 spring brake chamber (TKL brand), 45L air tank |
| Twistlocks | 4, 8, or 12 sets (lifting or screw Type) |
| Valve | WABCO valve |
| ABS | Optional |
| Light | LED light |
| Voltage | 24V |
| Socket(Receptacle) | 7-pin Socket (for 7 wire harness) |
| Tool Box | 1m × 0.5m × 0.5m (The tool box contains 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar. Its size can be tailored to suit your needs.) |
| Painting | Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats. |
| Shipping Terms | Transported by the bulk carrier in an RORO or 40HQ container. |
