| Tare Weight | about 6.8-8.6T |
| Dimension | 13000mm*2490mm*2860mm(Outerside)
12800*2300*1800mm |
| Loading Capacity (T) | ≤60 T |
| Axle | 13 T/16T, FUWA /BPW /Huajing Brand |
| Rim | 9.00-22.5 |
| Tire | 12.00R22.5/ 315 80R22.5 |
| Suspension | Mechanical suspension (Germany Type or America Type)
Or Air suspension (Chinabrand or BPW brand ) |
| Spring leaf | 90(W)mm*13(Thickness)mm*10 Layer or100mm*12mm*12 |
| King pin | JOST brand 2.0 or 3.5inch bolts type or Welding type |
| Support leg | JOST brand D200T orChinabrand 28Tons (Double speed) |
| Main beam | Height:500mm, upper plate is14mm, middle plate is8mm,
down plate is16mm; Material is Q345B Steel . |
| Side beam | 16mmor18mmchannel steel (Material is Q235steel). |
| Side Wall | 600mm-1800mm,the open door can be choose freely. |
| Brake chamber | WABCORE6relayvalve;T30/30+T30Springbrakechamber(TKLbrand); Two pieces of 45Lairtanks |
| ABS | Optional |
| Twist Locks | Four ,Eight or Twelve pieces (Lifting type or Twist Screw Type) ,optional |
| Valve | WABCO valve |
| Light | LED light |
| Voltage | 24V |
| Receptacle | 7 pin socket( for 7 wire harness) |
| Tool box | 1m × 0.5m × 0.5m (The tool box contains 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar. Its size can be tailored to suit your needs.) |
| Painting | sandblasted, anti-rust chassis surface is available with 1 coat of anticorrosive prime, 2 coats of final paint |
| Shipping terms | By Bulk cargo carrier,RORO or 40'HQ container |
