Construction Machinery 2 Ton Electric Hoist with Plain Trolley

Construction machinery 2 ton electric hoist with plain trolley



Technical Parameters:

Model	SSDHL
	02-01M
Capacity(t)	2
Lifting speed(m/min)	6.9 (Single Speed)
Motor power(kw)	3
Rotation speed(r/min)	1440
Insulation grade	F Class
Phase	3 phase
Power supply	220V to 690V / 50HZ or 60HZ
Control voltage	24V/36V/48V
No. of load chain	1
Spec.of load chain	10.0

1. Shell:
The shell is made of aluminum alloy.Light but hard.The cooling fin of motor frame and air cooled motor fan both ensure quick heat dissipation.They can reduce working temperature during frequent operation.The integral enclosed structure is applicable to places like chemical plant and electroplate factory.

2.Aluminum alloy die-casting body:
Play the role of bearing,tough and strong.After 900 tons die cast,the density becomes larger, this ensures that the body will not leak.

3. Gear:
The gear made of alloy steel and through the heat treatment

4. Antiphase protector:
When power-supply wiring mistake, the control circuit is unable to move.

5. Hooks:
They are made by hot forging and heat treatment.

6. Chain:
It is made of FEC80 ultra strong heat treatment alloy steel. Advatages: It is safely approximately when used in the rain water, the sea water, under the chemical and other bad conditions.

Production Workshop:

Chain block and electric chain hoist are distributed in different workshops.According to the classification of products,they are neatly placed in a wide work shop .The skilled workers are working meticulously.The test bench is used to check whether the product is qualified.



Quality Management:

The company has a comphensive and effective management system and TS16949 was approved in 2002 as well.From the market services, materials testing, planning, technical design, materials supply, product manufacturing, after-sales service, logistics supply and security guarantees and other aspects of closely linked.This is conducive to ensuring high quality and high efficiency of the project.



The Practical Application :

They are widely used in double beam crane,gantry crane,bridge crane,single grinder crane ,lifting platform ,workshop,construction buliding,etc.



The Certificate:

Our company obtained the approval of ISO9001 and CE certification from Europe,and our products have been exported to Europe,America,the Middle East,Africa and Southeast Asia.We become both domestic and foreign clients to select TXK hoisting equipment and establish long-term business relationship with us.



7 reasons to trust TXK:

Longest history and longevity - TXK is one of the oldest established electric chain hoist manufacturers in China,with almost 20 years.Largest factory and production capability - TXK factory is the biggest factory covering more than 56,000 square meters territory.Widest products and servuce providing - TXK can provide widest products itema include electric & manual lifting equipments.Richest experience in world business - TXK has more than 10 years experience on international trade business.Fastest lead times - TXK factory is equipped with most efficient producing line which handled by skillful workers.Fullest certifications - TXK factory and products are well certified by CE,GS,TUV,ISO,SGS,etc.Highest reputation - TXK products are well sold in more than 50 countries.
