Chain Block / Manual Chain Block

H-Lift Chain Block / Manual Chain Block CH-J Type:
1. Chain Hoist Capacity: 0.5T-10T
2. Standard lift: 2.5m/3m upon your request

H-Lift manual chain hoists are commonly known as chain blocks and are designed for heavy duty lifting and materials handling operations. Chain blocks raise and lower loads by pulling on the hand chain. Chain blocks can be of single or double fall configurations depending on the capacity of the block.

Asbestos free brake, holding load at any desired height.
- Robust all-steel construction.
- Top and bottom hooks are fitted with safety latches as standard.
- All rotating components mounted on roller or ball bearings to reduce friction & increase efficiency.
- The hoist is fitted with high grade alloy load chain & Overload Protection Devices are available upon request.
- Grade 80 Zinc Plated FEC CHAIN from Japan or RUD CHAIN from Germany are available upon request.
- Optional trolleys: Plain Trolley & Geared Trolley.

Model		CHJ005	CHJ010	CHJ015	CHJ020	CHJ030	CHJ050	CHJ100
Rated Load (W.L.L.)	tons	0.5	1	1.5	2	3	5	10
Standard Lift	m	3	3	3	3	3	3	3
Test Load	kN	7.5	15	24	30	48	75	150
Hand pull to lift full load	N	261	267	374	406	385	401	425
No. of falls Load chain		1	1	1	1	2	2	4
Load Chain	mm	5	6	8	8	8	10	10
Dimensions(mm)	A	129	156	172	184	236	261	364
	B	124	135	150	156	156	181	181
	C	281	307	369	446	521	521	701
	D	31.5	40.5	41.5	47	51	60.5	85.5
	K	35.5	31	33	36.5	43.5	51.5	63.5
Net Weight	Kg	7.1	10.4	16	16.3	24.1	35	87
Weight for additional one meter of lift	Kg	1.5	1.8	2.3	2.3	3.8	5.4	9.8
