Heavy Duty Motorized Transfer Cart for Aluminum Coil on Rail (KPD-30T)

Electricity operated rail die cart with operation platform

about company



Xinxiang Hundred Percent Electrical and Mechanical Co. Ltd is a collection of research, design, manufacture, installation and after-sales service as one of the professional manufacturing company. Our company has a modernized management team and has become the famous enterprise in the motorized transfer trolley business, depending on the advanced management methods and service concept, with the help of the local government's talent and environment support.

Working principle



The carts are powered by the low voltage electricity from the railways. The power source AC 380V is transformed into AC 36V two-phase and are respectively connected to the two rails. Then the flats' wheels conduct the AC 36V on rail into the electrical appliance box at the bottom of the carts. And then the AC 36V is transformed into DC 36V and then control the DC motor through the DC control system.

Technique Parameter

Model		KPDZ-2t	KPDZ-5t	KPDZ-10t	KPDZ-16t	KPDZ-20t	KPDZ-25t	KPDZ-30t	KPDZ-40t	KPDZ-50t	KPDZ-63t
Rated load		2	5	10	16	20	25	30	40	50	63
Table size	Length(L)	2000	3500	3600	4000	4000	4500	4500	5000	5500	5600
	Width(W)	1500	2000	2000	2000	2200	2200	2200	2500	2500	2500
	Height(H)	450	450	500	500	550	600	600	650	650	750
Wheel base		1200	2500	2600	2800	2800	3200	3200	3800	4200	4300
Rail Inner Gauage		1200	1435	1435	1435	1435	1435	1435	1435	1435	1435
Wheel Diameter		270	300	300	350	350	400	400	500	500	600
Wheel Quantity		4	4	4	4	4	4	4	4	4	4
Ground Clearance		50	50	50	50	50	50	50	50	50	75
Running Speed		0-25	0-25	0-25	0-20	0-20	0-20	0-20	0-20	0-20	0-20
Motor Power		1	1.2	1.6	2	2.2	3	3.5	4	5	6.3
Transformer Power		3	5	5	6.8	6.8	6.8	10	10	10	20
Transformer Quatity		1	1	1	1	1	1	1	1	1	1
Running Distance		80	80	80	80	80	80	80	60	50	50
Max Wheel Load		14.4	25.8	42.6	64.5	77.7	94.5	110.4	142.8	174	221.4
Reference Weight		2.8	3.6	4.2	5.5	5.9	6.5	6.8	7.6	8	10.8
Recommended Rail Model		P15	P18	P18	P24	P24	P38	P38	P43	P43	P50

OurCertificates



1. Meet JB/T6127-92 machinery industrial standards

2. Passed ISO9001 Quality management system requirement, SGS

3. Won the honor of 'National famous brand', 'Quality Products of Henan province', 'Quality and Credit Enterprise Consumer Trusted', 'The Contract Trustworthy Enterprise',

Our Customer



Production Supply Scope

Product Name	Model No.	Power Supply Mode	Load Capacity	Other Items	Usage
Rail Transfer Cart	KPD	Conductor Rail	Load range 1-300ton, can be customized per client demand	Running distance	Ordinary goods,such as steel plate, workpiece,equipment etc special goods,such as coil. column,ladle etc
Battery Powered Transfer Car	KPX	Battery		Using frequency
Motorized Transfer Trolley	KPJ	Cable Drum		Running distance
Busbar Powered Handling Cart	KPC	Busbar		Working shop
Towed Rail Trailer	KP	Tractor	1-100t	Working shop
Steerable Towed Car	BWT	Tractor	Load range 1-50t, less than 20t, cement floor is ok. More than 20t,steel floor is demanded.	Working environment
Trackless Handling Machine	BWP	Battery		Working path

Attentions
1. This series have strict requirement on the construction of the railways which need to be insulated. The rated load can not be more than 50T.

2. When running distance is more than 70m, you need to increase the transformers to make up the voltage which has been lowered.

After-sale service

In the warranty period, if our product has any problem or can't work normally, we can support you repair technology or replace relevant parts for you.

According to the user's actual condition, design the auxiliary device or foundation drawing for free, and offer the technical service and drawing material. Guide the customer to install and debugging of the trolley until making customer satisfied.

Our commitment:1> The load bearing safety factor of the trolley is no less than 120%.2>Freely design the auxiliary device or foundation drawing, and offer the technical service and drawing material 3> 16 hours engineering service and 24 hours internet service for our customers4> During the warranty period, if our products can't work normally, we can support you repair technology or replace relevant parts for you within 24 hours. 5> Solving the quality problem within 24 hours, serious attitude from beginning to end. Value the reputation and Preserve the image of our company.
