1. Quick Details
Transmission Type: Manual
Condition: New
Horsepower: 150 - 250HP
Emission Standard: Euro 3
Fuel Type: Diesel
Dimensions (L x W x H) (mm): 9990*2530*3820
Box Dimensions (L x W x H) (mm): 7410*2310*2310
Temperature Range: 0C- below 23C
Gross Vehicle Weight: 12495
Colour: Can be chosen by customer
We also supply you the other type of HOWO, 4*2, 4*4, 6*2, 6*4, 6*6, 8*4 different engine power(270HP, 290HP, 310HP, 330HP, 350HP, 380HP, and 420HP), EURO II, and EURO III dump truck. We could choose the right truck for you and co
nfirm that is your good assistant in your work.
2. Company introduce
HUBEI VELDLION MACHINERY CO., Ltd is an authorized Special Trucks manufacturer. We are specialized in the production of a variety of special-purpose vehicles.
Creating value for our customers is our company's concept. Welcome to enquiry from us, Let's our sales team make you more great in this field.
Our main products:
1. Heavy duty truck,
2. Fire engine truck
3. Truck mounted with crane
4. Dump truck
5. Water truck,
6. Fuel tanker,
7. Van truck, insulated truck, refrigeration truck
8. Fecal suction truck, sewage suction truck,
9. Co
ncrete mixer truck,
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Bulk cement truck,
13. Chemical liquid tank truck
| Loading capacity | 4-5TON | 7-8TON |
| Main specification | Chassis brand | ISUZU | ISUZU |
| Chassis model | QL10403 | QL1070 |
| Overall dimension(L*W*H) | 5995x1910x2790 mm | 6950x2130x3090 mm |
| The size of the cargo box(L*W*H) | 4100x1740x1750 | 5040×1900×1880 mm |
| Total weight | 4475 | 7300 kg |
| Curb weight | 2850 kg | 3690 kg |
| Rated Loading capacity | 1495 kg | 3480 kg |
| Chassis | Drive modle | 4x2 left hand drive | 4x2 left hand drive |
| Axle loading (front/rear) | 1800/2675 kg | 2580/4720 kg |
| Wheel base | 3360 mm | 3815 mm |
| Front/rear suspension | 1015/1620 mm | 1015/1015 mm |
| Front/rear track | 1385 mm | 1504/1525 mm |
| Spring number | 1425 | 8/6+5 |
| Tyre size & number | 7.00-16 | 7.00-16 |
| Max speed | 95 km/h | 95 |
| Engine | Manufacturer | ISUZU | ISUZU |
| Model | 4JB1CN | 4KH1-TCG40 |
| Engine Type | Diesel , 4 cylinder | Diesel |
| Horse power | 72/98 kw/hp | 88/120 kw/hp |
| Displacement | 2771 ml | 2999 ml |
| Emission | Euro 4 | Euro 4 |
| Cargo box | Overall dimension(L*W*H) | 4200x1900x1850 mm | 5040×1900×1880 mm |
| Material | color plate in the surface, inside foam | color plate in the surface, inside foam |
| Cargo Thickness | 8 mm | 8 mm |
| Refrigerator model | DT-150S or KBL30 | DT-230 or KBL50 |
| Working Temperature: | -18° | -18° |
