Detailed Description
HOWO 10, 000L Sewage suction truck
Model&co
lon; ZZ1167M4611
Driving type&co
lon; 4× 2
Cab&co
lon; HW70, 2 seats
Engine&co
lon; 266HP
Transmission&co
lon; 10 forward and 2 reverse
Front axle; HF7
Driving axle&co
lon; ST16
Tire&co
lon; 12R22.5(Including one spare tire)
Sewage suction body&co
lon; 10m3
| Model | Drive mode | ZZ1167M4611 |
| Model | 4×2 |
| Cabin | Type | HW70,2 seats,no bed,right hand drive,with air coditioner |
| Engine | Model | WD615.62 |
| (cc)Displacement | 9.726 |
| (Hp/rpm)Max output power | 266/2200 |
| (N.m/rpm)Max torque | 1160/1100-1600 |
| Transmission | Model | HW15710,10 forward and 2 reverse |
| gear ratio | 14.28, 10.62, 7.87, 5.87, 4.375, 3.26, 2.43, 1.8, 1.34, 1, 13.91(R1), 3(R2) |
| Clutch | Mode |
Single plate,dry clutch |
| Rear Axle | Model | ST16 (ratio:4.42) |
| Main parameter | (mm)Overall Dimension | 8300*2496*2958 |
| (mm)Wheel base | 4600 |
| (mm)Tread | 2022/1830 |
| (mm)Suspension arm | 1500/1890 |
| (Kg)Curb weight | 10000 |
| (Kg)Rated payload | 13000 |
| (Kg)GVW | 23000 |
| (Km/h)Max speed | 102 |
| Sewage suction body | cargo box dimension(L) | 10,000 |
| Pump | Including |
| Tire | Type | 12R22.5(Including one spare tire) |
| Steering system | Power steering |
| Brake system | Mode | Dual-circuit air brake |
| Parking brake | spring energy,compssed air operation on rear wheels |
| Auxiliary brake | engine exhaust brake |
| Emissions standards | EUR II |
