Detailed Description
1. im
ported steel from Sweden
2. Famous chassis SINOTRUK HOWO
3. Power diesel engine WD615 series
4. Radial tyre 12.00R20
5. Good performance and timely delivery
| name | unit | parameter |
| HDT5291THB-37/4 |
| output in theory | m3/h | 150 |
| index of the pump carry capacity | Mpa.m3/h | 586 |
| theoretic pumping pssure | Mpa | 8.5 |
| bucket volume | L | 700 |
| height of top surface of bucket | mm | 1370 |
| model of dirstribution valve | | S |
| max. operation radius | m | 32.6 |
| max. operation height | m | 36.6 |
| max. operation depth | m | 25.5 |
| open height of boom | mm | 8450 |
| distance between front landing legs | mm | 7058 |
| distance between rear landing legs | mm | 6848 |
| distance between front & rear landing legs | mm | 6790 |
| diameter of delivery pipe | mm | 125 |
| length of hose pipe | m | 4 |
| rotary range of boom | | 365° |
| quantity of boom | | 4 |
| rotary angle of each boom | ° | 92/180/180/270 |
| wire line control distance | m | 33 |
| remote control distance | m | 200 |
| max. speed | km/h | 90 |
| min. turn radius | mm | 8800 |
| brake distance | m | 7 |
| approach angle | ° | 16 |
| departure angle | ° | 11 |
| chassis model | | ZZ5307N4647C |
| wheel base between the first & the second axle | mm | 4600 |
| wheel base between the second & the third axle | mm | 1350 |
| front tread | mm | 2022 |
| rear tread | mm | 1830 |
| max. engine output power | kw | 247(2200r/min) |
| max. engine output torque | n.m | 1350(1100-1600r/min) |
| max, gradient ability | % | 35 |
| fuel consumption | L/100km | 34 |
| out dimension(L×W×H) | mm | 12000×2490×3850 |
| total weight | kg | 29000 |
Product Image
