Detailed Description
SINOTRUK HOWO 6x4 8m3 Co
ncrete Mixer Truck (ZZ1257N3641W)
ba
se information:
HOWO 6x4 Co
ncrete Mixer 8m3
1. Engine: 336Hp
2. Drive: LHD/ RHD
3.Effective volume: 8m3
4. Italy Bo
nfiglioli reduction box;
5. USA Eton Pumps and motors;
6. Tanker color: white
8m3 co
ncrete mixer truck specification:
| SINOTRUKHOWO6x4 New Mixer TruckZZ1257N3641W |
| LHD OR RHD |
| Engine: | Model: CNHTC brand WD615.69,336hp, euro II emission; |
| Transmission: HW15710, 10 speed; |
| Gear box | 430 single plate dry diaphragm , hydraulically with air assist. WD615.69 with 430B; |
| Steering: ZF8118 Steering gear box; |
| Front axle: HF9, rated loading:9T; |
| Driving axle: HC16 double reduction driving axle, Ratio: 5.73; |
| Cab: | Model: HW76; |
| Length cabin, 1 bunk, with A/C, adjustable steering wheel, VDO panel, control module, safe-belt with 2 locks, outer sun shade. |
| Tyres:12.00R20 radial tyre |
| Brake system | Driving brake: dual circuit compssed air brake |
| Parking brake: spring energy, compssed air operating on rear wheels |
| Auxiliary brake: EVB+ engine exhaust |
| Electric system: CAN bus control, voltage: 24V, alternator: 1540kw; starter: 7.5KW; battery: 12V/165Ah, 2 pcs. |
| Chassis dimension: 7775x2496x2958mm; |
| Axle base: 3625+1350mm; |
| Wheelbase ( front/ rear): 2022/1850; |
| Min. ground clearance: 314mm; |
| Max. speed: 75Km/h; |
| Max. climbing capacity:≥50%; |
| Whole truck dimensions: 8715mmx2496mmx3850mm; |
Effective volume: 8m3
Italy Bonfiglioli reduction box;
USA Eton Pumps and motors;
Tanker color: white |
