Electric Standing Power Wheelchair (THR-FP130)

Product Description
Electric wheelchair
-Standing wheelchair
-Standing, seat and lay down function
-Easy operate
-Your good helper in daily


THR-FP130 Electric Standing Power Wheelchair
Seat and Stand up function, with protect belts on the chest and legs;
It can be lay down at any position according to your need easily;
The arm rest is openable, for nursing staff to help user more easily.
With handle rails, for user to up and down seat, and also can put dining table over it.

The Head rest is adjustable freely upward and downward;

Wheels with Sway castors to confirm user's safe.
Handle controller, with speed indication and power indication.

Max speed	≤7 km/h	Mileage	≤30km
Total weight	95 kg	Battery weight	30 kg
Climbingangle	≤15°	Brake distance	≤1.5m
Parking angle	≤15°	Obstacle height	≤30mm
Stand time	15s	Lying time	15s
Groove width	≤50mm	Work environment	-20C°~ 45C°
Battery	4×20Ah	Rated voltage	24V
Motor power	2×250W	Motor voltage	DC24V
Charge input	AC220V50HZ ±15	Charge output	DC28.8V
Charge output	5A	Charge time	10 hours
Static stability	Vertical 15° Lateral 10°	Dynamic Stability	Uphill 10° Downhill 8° Turing 5°
Max load	≤100kg	Age	<5 years
Storage Environment	Packaged products should be stored in the vessel or indoor where the ambient temperature is -10°-50°and relative humidity is less than 90%. There are no corrosive liquids or gas, no strong mechanical vibration. The storage must be clean and has good ventilation
