Detailed Description
HOWO 6X4 Garbage Compactor Truck-16CBM
| Cabin | HW 76 Standard Cab, with two seats, one bed, 70° hydraulically tillable to the front as attached photo for ref. LHD | |
| Vehicle Main Dimensions | (L x W x H)mm | 11000x2500x3330 |
| Wheel base (mm) | 3825/1350 |
| Wheel track (front/rear) (mm) | 2022/1830 |
| Approach/Departure angle(°) | 19/10 |
| Weight in KGS | Tare Weight | 15440 |
| Front axles loading capacity | 1x9000 |
| Rear axles loading capacity | 2x16000 |
| Rated Loading Capacity | 16CBM |
| Max. driving speed(km/h) | 75 |
| Engine | Brand | SINOTRUK |
| Model | WD615.95C |
| Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling |
| Horse Power(HP) | 340HP |
| Emission standard | Euro ‖III |
| Gearbox | HW19710, 10 forwards & 2 reverse |
| Clutch | Reinforced diaphragm clutch, diameter 430mm |
| Steering Gear | ZF 8098,power steering, hydraulic steering with power assistance |
| Fuel tank (L) | 300 |
| Tire | 295/80R22.5 tubeless tyre, total 11 pieces |
| Brakes | Service brake: dual circuit compssed air brake
Parking brake :(emergency brake): spring energy, compssed air operating on rear wheels
Auxiliary brake: engine exhaust valve brake |
| | | | |
Outline drawing of compssed garbage truck
Hydraulic valve assembly
Pushing board,sliding board ,scraper board , manual operating lever
Pushing board and power operating button
