| Item | Description |
| Technical parameter | Overall dimensions | 6300mm×1620mm×2300mm |
| Unloading weight | 1800kg |
| Min. ground clearance | 150mm |
| Max. speed(loaded) | 30-35km/h |
| Max. distance range | 60-80km |
| Max. climbing ability ( loaded ) | 10% |
| Min. turning radius | ≤ 6.5m |
| Passenger capacity | 23 |
| Electric system | Battery | double 8*6V/180AH, total 16pcs lead-gel |
| Charger | automatic and intelligent |
| Controller | Curtis |
| Motor | 48V/6.3KW DC series excitation |
| Lighting system and horn | 2 combined front lights(headlight, turning light, position light), 2 front fog lights, 2 taillight(turn signals and brake lights), horn, rear buzzer |
| Dashboard meter | voltammeter, ammeter, odometer, emergency switch; combined switch, meter indicator |
| Audio System | radio and MP3 adaptor, with 2 speakers |
| Wiper | single arm |
| Steering and suspension | Transmission system | rear engine Rear wheel drive(RR) |
| Steering system | gear rack type steering machine, automatic clearance compensation function, electric power steering |
| Front axle and suspension | independent suspension, cylinder hydraulic vibration absorber |
| Rear axle and suspension | integrated rear end, steel plate spring suspension, cylinder hydraulic vibration absorber |
| Braking system | Vacuum brake + hand brake |
| Wheel & tyre | steel rim, tubeless tyre600-14 |
| Body and frame | frame | high quality carbon pipe welding rust frame |
| Body | Fiber glass |
| Windshield | designed front and rear laminated glass |
| Side rear view mirror | each on both sides |
| Interiors System | Seats | senior fabric leather + higher rebound PU |
| Steering wheel | PU foaming steering wheel |
| Floor | alumnium alloy plate |
| Accessory: charger, one set of general tool, rain curtain, seat belts |
