| TECHNICAL DATA |
| Size |
| //Length/Width/Height (mm) | 7990×2450×3380 |
| Interior height (mm) | 1900 |
| Engine |
| Engine model | CUMMINS I ENGINE diesel engine EQB160-20(Euro 2) |
| Engine type | front mounted,4stroke,turbo-charged,water cooledsystem, |
| Max.power/rotating speed (kw/r/min) | 118/2200 |
| Max. torque/rotating speed (N.m/r/min) | 490/1100-1500 |
| Displacement(L) | 5900 |
| Performance |
| Chassis model | HENAN SHAOLIN BUS CO.LTD Full chassis with Electrophoresis Coating |
| Top speed (km/h) | 125 |
| Axle distance (mm) | 3800 |
| Angle of approach / departure (º) | 13.5/8.4 |
| Wheel track(front/rear)(mm) | 1860/1680 |
| Brake distance (v=30km/h fully loaded) | <10m |
| Fuel tank volume(L) | 135 |
| Fuel consumption (on certain condition) | ≤9.5 |
| Gross weight/Curb weight(kg) | 9400/6450 |
| Basic Specification |
| Clutch | Single,dry, diaphragm type, |
| Transmission | 5 forwardsmanual |
| Rear axle | Integral axle housing, single reduction final drive |
| Front axle | Ends fist,section |
| Suspension system | Leaf spring |
| Steering system | Integral power steering, LHD |
| Braking system | Dual circuit air brake, drier, energy storage spring chamber |
| Tire | 7.50-20 |
| Functional Specification |
Body type | The body of bus is welded by SS400 rectangular steel tube. side panels are stretched high-quality galvanized panels. The bottom of the chassis is specially treated with anti-corrosion glue. The whole bus is heat insulation. three step, |
| Interior trim | Air conditionerinterior trim,double face interior luggage rack with reading lamps and A/C ventilators, luxury air change fan type safety ceiling window, luxury rear-view mirror,concaved floor with wear-resisting vinyl |
| Door and door pump | luxury outward swingingpassenger door |
| Window | Pull-push window, folding curtain |
| Seat and accessories | 35seatshigh-back seats,safety belts |
| Video and Audio | USB MP3 player+Radio |
| Lamp | Integral front lamp, front ceiling height lamp, side mark lamp,high-level brake lamp |
| Service equipment | E-clock, engine compartment automatic fire extinguisher, 8KG fire extinguisher, vehicle tools, 4 safety hammers |
