| Dimenssion | Length(mm) | 10505 | Engine Data | Engine Model | EQB180 (DF Commins engine) |
| Width(mm) | 2500 | Engine Type | In line, 6 cylinder, 4stroke |
| Height(mm) | 3040 |
| Tread(mm) | 5000 | Displacement(L) | 6.234 |
| Wheel base F/R(mm) | 2020/1800 | Max. Powe(KW/rpm) | 132/2600 |
| Overhang F/R(mm) | 2275/3230 | Max. Torque(N.m/rpm) | 700/1400-1600 |
| Approach/Departure (°) | 8/8 | Fuel Type | Diesel |
| Performance | Chassis Manufacture | Hengtong | | Max. Speed(km/h) | ≥75 |
| Curb Weight(Kg) | 7400 | Max. Grade Ablitiy(%) | ≥20 |
| Engine Position | front | Min. Turning Diameter(m) | ≤24 |
| Brake distance(m) (V=30km/h) | ≤10 | Fuel Tank Capacity(L) | 150 |
| Axle F/R(kg) | 5000/9000 | Max. Total Weight(kg) | 13000 |
| | |
| Item | Standard Configiration | |
| Chassis | Clutch | Single dry plate spring clutch, Friction disc outer diameter 380 |
| Transmission | FAST mechanical Transmission with synchronizer, 5 forward speed 1 reverse speed | |
| Rear Axle | 9T Axle,Automatic clearance adjusting arm | |
| Front Axle | 5T Axle,Automatic clearance adjusting arm | |
| frame | parallel structure; vertical frame: front end as rectangle rear end as trough model section | |
| Suspension System | multi-pieces leaf spring(F:10/R:12), hydraulic shock absorber | |
| Steering System | Integral power steering gear | |
| Brake System | Dual-circuit pneumatic brake ,F/R drum brake ,Energy storage spring brake, ABS | |
| Tire | 9.00-20-16 | |
| Electric System | 24Vmongline , cathode ground connection | |
| Starter | 24v,Electromagnetism Control type | |
| Battery/Generator | 6-Q-195, 2 pieces/ 28v, 70A | |
| Other | | |
| Body | Body Structure | Semi monoque, Cold-bend type steel framework, Pre-stressed pull skin, fiber glass for F/R surround | |
| Interior Trimming | ABS absorb plastic interior fitting, PVC agglutination roof and side panel, Polyester frothing roof-side board, absorb plastic front lamp box, Rear lamp box of fiber glass ,absorb plastic door pump box ,Integral Polyester shaped instrument console, rolling curtain for sun visor; curtain for side window | |
| Door& Door Pump | Front single, mid double Inwards swing Aluminum alloy door, electrical pneumatic door pump | |
| Window | Front /rear cemented windscreen, top fixing and bottom pull-push type side window, 3 standard roof windows | |
| Floor | 3 stage-step bus, Bamboo board with Standard floor, Press-punched aluminum floor for horizontal, vertical surface of step | |
| Seat | 2+2 arrangement,34 plastic seat,one adjustable driver seat | |
| A/C System | optional (+3500USD) | |
| Handrail & Ring | Colorful spray handrail, ring | |
| Audio & Visual | Mp3 vehicle player | |
| Rear View System | Newman rear view mirror KW28 | |
| Lamp | Combination headlamp, split type tail-light, 4 LED independent inner roof lights | |
| Wiper | Asynchronism panorama wiper ( with water spray ) | |
| Servcie Facility | Electron clock, Aluminum frame tool box,two 2KG Extinguishers for Vehicle Interior, F/R lighting guidepost, plastic garbage can, Roof fan for driver, electric fan. | |
| Other | Polyester paint, atomic ash | |
