40feet 3axle Flatbed Truck Semi Trailer

40feet 3axle Flatbed Truck Semi Trailer



Main Product Specification:

Main technical parameter	JSX9240FCT
Detailed instructions	3 axles 40FT Flatbed semi trailer
G.W./kgs	35,490
Tare Weight/kgs	7,490
Rated load/kgs	28000
Overall Size(L*W*H/mm)	12250, 2490,1490/1520
Axle base/mm	7000+1310+1310
Tire Size	11.00R20;11.00-20;10.00-20
Wheel base/mm	1,830
Leaf spring/pcs	7/7/7;8/8/8
Front/rear suspension(mm)	450/2180
Saddle bearing capacity/kgs	11,700
Rear axle bearing capacity/kgs	23,790

More types of the flatbed container semi trailer for your options:

20ft-52ft /30-65TONS ConTAINER LOAD SEMI TRAILER (FLATBED)
Dimension	Model	Axles/ Tires		Rated Capacity
20ft	JSX9200GYY	2 axles/8 tires	3 axles/12 tires	30T-45T
30ft	JSX9201GYY	2 axles/8 tires	3 axles/12 tires	30T-45T
40ft	JSX9202GYY	2 axles/8 tires	3 axles/12 tires	45T-60T
45ft	JSX9303GYY	2 axles/8 tires	3 axles/12 tires	40T-65T
48ft	JSX9304GYY	2 axles/8 tires	3 axles/12 tires	40T-65T
52ft	JSX9305GYY	2 axles/8 tires	3 axles/12 tires	40T-65T

Advantages:

Research and development means:
using the most advanced techniques and tools: FEA (finite element) analysis, PRO-E design, effective guarantee of
product quality and overall reliability.

The main structure:
main steel structure adopts 16Mn high-strength structural steel,the strength is 1.6 times that of the ordinary steel frame,
and the main beams adopts uniform cross-section design to achieve the best supporting effect.

Walking mechanism:
national patent product, wear resistant suspension system.

Braking system:
adopting the international famous brands'full set of brake systems,equipped with ABS systems.

Electrical system:
using the domestic famous brand, original complete set, sealed wire harness ,with ISO standard of seven-pin socket.

Surface Coating:
processed materials,vehicle shot blasting,undercoat processing,topcoat spraying four fine processes,adopting
international famous brands of paint, surface treatment achieve the level of Sweden Sa2.5 ocean anti-corrosive standards.

Comply with the regulations:
full compliance with GB1589, GB7258 etc. standards.

Details:


Quality Control:
1- For Each trailer, we must do the testing and inspect the quality.

2-You wil get the inspection certificate according to customer demand for every trailer which given by an independent third
party certification company.

3- You will get the out-standing quality assurance
