Tare weight | 9000kg | Payload | 50000 kg | ||||||||||
Overall length | 12500mm | Overall width | 2550mm | Overall height | 3930mm | ||||||||
SPECIFICATION | |||||||||||||
Chassis | Heavy duty and extra durability designed I beam;opting for high tensile steel Q345,welded by automatic submerged-Aac processes.Top flange 14mm,width140mm;Middle Flange 8mm;bottom flange16mm,width 140mm | ||||||||||||
Axle | Number | 3 | Brand | Fuwa | Capacity | 13T | |||||||
Suspension | Mechanical suspension | ||||||||||||
Leaf spring | 10 pcs | ||||||||||||
Floor | 3mm .checkered plate | ||||||||||||
Tire | 12R22.5 double brand 12pcs | ||||||||||||
Wheel rim | 9.0 12 pcs | ||||||||||||
Kingpin | 2'' bolt-in king pin | ||||||||||||
Landing gear | Fuwa two-speed,manual operating ,heavy duty landing gear 28T | ||||||||||||
Twist lock | No | ||||||||||||
Vehicular applications | Cargo transport | ||||||||||||
Drawing | Including | ||||||||||||
Braking system | RE6 relay valve ;T30/30 spring brake chamber;40L air tanks .24V | ||||||||||||
Paiting | Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint | ||||||||||||
Accessories | One standard tool box | ||||||||||||
