Detailed Description
| Electric system | |
| Motor power(W and type) | 500W 8FUN geared hub motor/super high speed winding/shimano cassette |
| Controller | 9 transistor/ Sine wave |
| Throttle | thrumb throttle optional |
| Display (type 1) | LCD display/standard display/5 level assist:ECO,1,2,3, Sport(45kmph) |
| Display (type 2) | compliance display/4 level assist: ECO,1,2,3(max 32kmph) (can limit to 25kmh) |
| Wire harness | 1-to-4 quick connector/brass lock-ring/water resistance |
| Charger | 48V 2A/UL certified |
| Sensor | torque sensor(rear drop-out frame-mountedstrain gauge) |
| Battery option | 48V8.8AH LG cell/extended 48V12.8AH Samsung lithium battery cell |
| Brake (mark, model and type) | Tektro HD-E350 hydraulic disc brake |
| Transmission | |
| Derailleur (mark model and speeds) | Shimano Alivio 9-speed 11-32T/trigger shifter |
| Front chainring | Prowheel 52T CNC |
| Crank | 170mm |
| Chain | KMC |
| Fork suspension (mark and type) | Suntour NCX with hydraulic lockout |
| Handlebar&stem | Promax handlebar&stem grip:Velo lock-on |
| Seat post &seat | Promax 27.2mm/quick release/Selle Royal gel |
| Pedal | Wellgo /sealed bearing |
| Wheels&tires | Kenda K1088/700C*45C |
| Spokes | Stainless F:13G R:12G |
| frame (type and material) | AL6061 heat treated/integrated &removable down-tube battery |
| frame size | M 17.5'/L 19.0'/XL 20.0' |
| Color | Red clear coat with black graphics/black matt with clear coat graphics |
| Speed (km/h) | Max. pedalling 45kmh ;throttle optional |
| Range Throttle km, PAS km | throttle 45km; PAS 65km(10.4AH battery) |
| Loading | 75-100kg |
| N.W(with battery) Kg | 23.4kg |
| Weight of battery (Kg) | 2.9kg |
Company Information
Luyuan stands for green power in Chinese, was founded on July 3rd, 1997, and was one of the earliest specialized in electric vehicle R&D and manufacturing in China. With 20 years' development, Luyuan has grown into a large-scale modern group with R&D, manufacture, sales and after-sales as a whole. Now it has 5 business manufacture units distributed in Zhejiang, Shandong, Jiangsu, Guangdong, and Fujian province, with over 4000 employees, over 1000 sales distributors and 10,000 people in relevant and with a production capacity of 2million e-vehicles(including e-bike, e-scooter, e-tricycle and other e-vehicles).
Luyuan vehicles are distributed to over 60 countries, such as USA, Canada,, France, Italy, Spain, Japan, Korea, India, Malaysia, Brazil etc. Today Luyuan has become one of the largest electric vehicles manufacturer and the most respected e-vehicle brand in China.
Product Image
