Detailed Description
We are a leading manufacturer of
tow truck,we can provide tow truck and devise tow truck with famous chssis.Allbrand recovery truck include SINO,FAW ,FOTON,JAC,NORTH BENZ,DONGFENG,HINO,SHACMAN,ETC ,Drive type from 4x2.4x2,6x2.6x4,6x6,flatbed tow truck andwrecker truck , capacity from 3Ton o 40on .
Our gurantee period is 12mo
nths or 8000KM which comes first .
so if you have such requirements ,please co
ntact me with TM:truck2011 or cell phone 86-13872885121 .
Specification ofbrand new factory sales do
ngfeng 5Ton road wrecker truck
| Chassis parameter |
| Whole vehicle main dimensions | overall dimension(LxWxH)mm | 5990x2080x2480,2660 |
| Drive system | 4x2 |
| wheel base(mm) | 3800 |
| Weight data | curb weight(kg) | 4500 |
| GVW | 7695 |
| Whole vehicle main performance | Max speed(km/h) | 93 |
| Engine | Engine | CY4102-CE4B |
| displacement | 3856mL |
| Max output | 136HP |
| Max torque/speed | 420N.m@1400-1800r/min |
| Gearbox | gear box | Dongfeng 5Speed , 5forward ,1 reserve |
| Front/rear axles | 2.5T/5T |
| tyre size | 7.50-16 |
| Special parts parameter |
Tow Function
(crane and lifter are together) | Max tow capacity | 7.5Ton |
| Max tow lifting capacity
(shortest arm position) | 2.5Ton |
| Max tow lifting capacity
(longest arm position) | 1.96Ton |
| Max Lift weight | 3Ton |
| Max lift height | 2.7M |
Photo ofbrand new factory sales do
ngfeng 5Ton road wrecker truck
Cerificate of factory :
