Detailed Description
Manual Pulley
Model&co
lon; PC-02
Capacity(ton)&co
lon; 2
Minimum radius of turn(m)&co
lon; 1
Net Weight (kg)&co
lon; 6.2
Designed to function on both flat and minor irregular beams surface like I-beam and H-beam
Easy installation and on-site operations
Dual tread iron wheels with high quality sealed ball bearing
Heavy rolled steel side plates with a universal hanging eye, can be coupled closely to most hoists.
Manual Trolley Manual Crawl specifications&co
lon;
| Manual Trolley Technical Parameters |
|
| Model | capacity | Unit(mm) | Minimum radius of turn |
| F | G | P | J |
| PC-0.5 | 0.5 | 200 | 130 | 163 | 91 | 0.6 |
|
| PC-01 | 1 | 190 | 135 | 160 | 90 | 0.6 |
|
| PC-02 | 2 | 200 | 170 | 221 | 115 | 1 |
|
| PC-03 | 3 | 218 | 205 | 265 | 138 | 1 |
|
| PC-05 | 5 | 275 | 236 | 305 | 157 | 1.2 |
|
What makes us different from others?
1. Production Capacity
*Over 96,000 square meters factory territory.
*Maximum daily capacity of new electric hoist can reach to 300 units.
2. Qualifications
*TXK is ISO9001&co
lon;2008 cerfified company.
*Factory authorized by TUV Germany.
*CE & GS certificates for all products.
3. Marketing
*TXK is well soldin more than 60 countries.
*We serve over 2,000 companies in the world, include "500 Fortune Enterprises".
*Best price in Competitors of same products
What else you can get from us?
| *Electric Chain Hoist |
| *Wire Rope Hoist |
| *Crane & Crane Components |
| *Chain Block |
| *Lever Block |
| *Manual Trolley |
| *Wire Rope Pulling Hoist |
| *Hand Winch |
| *Permanent MagneticLifter |
| *Jack & Scale |
| *Plate & Drum Clamp |
Product Image
