Chinese Products Manual Lifting Trolley for Hand Chain Hoist

Chinese products manual lifting trolley for hand chain hoist


1. Introduction of Chinese products manual lifting trolley for hand chain hoist
Heavydutytrolleysdesignedforflexibilityofinstallation.
Usableonstraightorcurvedtrack.
Easyadjustmenttothesizeofthesteelbeamusingcrank;
Simplyremoveendnutandadjustspacers.
Canbeinstalledorremovedfromanypointinthetrack.
Movementisachievedthroughpushing
2.Parameters of Chinese products manual lifting trolley for hand chain hoist

Capacity(T)	I-Beamwidth(M)	N.W. (KGS)	RatedLoad(KN)	Dimensions(MM)
				A	B	C	H
0.5T	68-126	7.8	6.25	283	200	200	150
1T	80-146	11.2	12.5	317	216	253	170
2T	80-168	13	25	360	260	310	180
3T	88-168	27	37.5	380	300	357	180
5T	100-180	39	62.5	400	345	400	210
10T	122-203	86	125	443	395	520	220
20T	122-203	220	250	465	630	568	290

3.SixAdvantages
1)08Aluminumcoldplate:Outercastercasingismadeof08Aluminumcoldplate,morethicken,higheffectofcollisionavoidance.Coloruseblackmattepaintprocessingdirtyrustresistance.
2)Thickenhooks:Hooksarebeprofessionalandtechnicalmeasured,morethicken,noteasybreak,strongstrength.
3)Simplestructure:Monorailtrolleywheelseasytospacing,suitformostofI-Beam,forceofpullingissmall,andthewheelissmall,itiseasytodriveinthetrack.
4)Exquisitedetail:Hightemperatureresistance,rustlessandavoidingfalloff.
5)Simplestructure:Partofstructureissimple.Simpleandeasytouse,lighthandpull.
6)Edgedesign:Collisionavoidancefunction.

4.FAQ


1. Is your product customized?
Thanks for your question. Yes, because the working condition are different, all our products are customized dependingon detail requirement! So if you give us more information about the lift capacity, span, lift height, power source and other specials, we will give you a very quick quote!

2. What's the information should I provide when inquiry?
Thanks for your question. The more information you provide, the accurate solution we can ppare for you! The information such as the lift capacity, span, lift height, power source or other specials you give us will be more appciated.

3. How many operating methods for my selection?
Thanks for your question. The standard operating methods we provide is pendent controller with push buttons. Meanwhile, we can also provide the remote control with push buttons and the cabin (space capsule seat) control with joystick. You can choose any of them, just tell us!

4. The space of my workshop is limited, can the crane ok for mine?
Thanks for your question. For low headroom workshop, we have the Special products. The detail dimension please consult our professional engineer.

5. What's the information should I provide when inquiry?
a. What's the lifting material?
b. How much is the maximum lifting weight of the hoist?
c. Have you installed the rails? Do you need us supply the rails? How long is it?
d. Where are the working environment?
