3ton Geared Trolley with Ce

Manual Pulley, Geared trolley, Manual Crawl
Model: GT-10
Capacity(ton): 10
Minimum radius of turn(m): 1
Net Weight (kg): 90

Designed to function on both flat and minor irregular beams surface like I-beam and H-beam
Easy installation and on-site operations
Dual tread iron wheels with high quality sealed ball bearing
Heavy rolled steel side plates with a universal hanging eye, can be coupled closely to most hoists.

Manual TrolleyManual Crawl Geared trolleyspecifications:

Manual Trolley Technical Parameters
Model	Capacity	I-Beam recommended A (mm)	I-Beam recommended B(mm)
				N.W.(kg)
GT0.5	0.5	75-125		10
GT1	1	80-146	64-140	14
GT2	2	80-168	76-165	16
GT3	3	88-168	76-203	24
GT5	5	100-170	88-203	36
GT10	10	122-203	125-203	90

What make us different from others?

1. Production Capacity
*Over 96,000 square meters factory territory.
*Maximum daily capacity of new electric hoist can reach to 300 units.

2. Qualifications
*TXK is ISO9001:2008 cerfified company.
*Factory authorized by TUV Germany.
*CE & GS certificates for all products.

3. Marketing
*TXK is well soldin more than 60 countries.
*We serve over 2,000 companies in the world, include "500 Fortune Enterprises".
*Best price in Competitors of same products

What else you can get from us?

*Electric Chain Hoist

*Wire Rope Hoist

*Crane & Crane Components

*Chain Block

*Lever Block

*Manual Trolley

*Wire Repe Pulling Hoist

*Hand Winch

*Permanent Magnetic Lifter

*Jack & Scale

*Plate & Drum Clamp
