Technical Data of WP5Gas Engine
Model | WP5NG165E40/E50 | WP5NG180E40/E50 |
Type | In-line, water cooling, wetliner, turbocharged and intercooled, electronically controlled p-mixing, spark ignition, lean burn | |
Number of cylinders | 4 | |
Bore(mm) xStroke(mm) | 108×130 | |
Total displacement(L) | 4.76 | |
Rated power(kW/ps) | 121/165 | 132/180 |
Rated speed(r/min) | 2300 | |
Max torque(N·m/speed r/min | 560/1300-1600 | 600/1300-1500 |
Standard fuel | LNG/CNG | |
Minimum fuel consumption rate(g/kW·h) | ≤185 | |
Idle speed(r/min) | 650±50 | |
Technical Data of WP6Gas Engine
Model | WP6NG210E40/E50 | WP6NG240E40/E50 |
Type | In-line, water cooling, wetliner, turbocharged and intercooled, electronically controlled p-mixing, spark ignition, lean burn | |
Number of cylinders | 4 | |
Bore(mm) xStroke(mm) | 105×130 | |
Total displacement(L) | 6.75 | |
Rated power(kW/ps) | 155/210 | 176/240 |
Rated speed(r/min) | 2300 | |
Max torque(N·m/speed r/min) | 680/1300-1500 | 780/1300-1500 |
Standard fuel | LNG/CNG | |
Minimum fuel consumption rate(g/kW·h) | <185 | |
Idle speed(r/min) | 650±50 | |
Technical Data of WP7 Gas Engine
Model | WP7NG240E40/E50 | WP7NG260E40/E50 |
Type | In-line, water cooling, wetliner, turbocharged and intercooled, electronically controlled p-mixing, spark ignition, lean burn | |
Number of cylinders | 6 | |
Bore(mm) xStroke(mm) | 108×130 | |
Total displacement(L) | 7.5 | |
Rated power(kW/ps) | 176/240 | 191/260 |
Rated speed(r/min) | 2300 | |
Max torque(N·m/speed r/min) | 900/1300-1500 | 980/1300-1500 |
Standard fuel | LNG/CNG | |
Minimum fuel consumption rate(g/kW·h) | <185 | |
Idle speed(r/min) | 650±50 | |
Technical Data of WP10 Gas Engine
Model | WP10NG280E40/E50 | WP10NG300E40/E50 | WP10NG336E40/E50 |
Type | In-line, water cooling, wetliner, turbocharged and intercooled, electronically controlled p-mixing, spark ignition, lean burn | ||
Number of cylinders | 6 | ||
Bore(mm) xStroke(mm) | 126×130 | ||
Total displacement(L) | 9.726 | ||
Rated power(kW/ps) | 206/280 | 221/300 | 247/336 |
Rated speed(r/min) | 2200 | ||
Max torque(N·m/speed r/min) | 1060/1400-1600 | 1230/1400-1600 | 1350/1400-1600 |
Standard fuel | CNG/LNG | ||
Minimum fuel consumption rate(g/kW·h) | <185 | ||
Idle speed(r/min) | 650±50 | ||
Model | WP12NG350E40/E50 | WP12NG380E40/E50 |
Number of cylinders | 6 | |
Bore(mm) xStroke(mm) | 126×155 | |
Total displacement(L) | 11.59 | |
Rated power(kW/ps) | 257/350 | 280/380 |
Rated speed(r/min) | 2200 | |
Max torque(N·m/speed r/min) | 1400/1400-1600 | 1500/1400-1600 |
Standard fuel | CNG/LNG | |
Minimum fuel consumption rate(g/kW·h) | <185 | |
Idle speed(r/min) | 650±50 | |
Technical Data of WP12HPDI Gas Engine
Model | WP12HPDI480E50 |
Type | In-line, water cooling, turbocharged and intercooled, direct injection compssion ignition |
Number of cylinders | 6 |
Bore(mm) xStroke(mm) | 126×155 |
Total displacement(L) | 11.596 |
Rated power(kW/ps) | 353/480 |
Rated speed(r/min) | 2100 |
Max torque(N·m/speed r/min) | 1970 |
Speed under max torque(r/min) | 1200-1500 |
Minimum fuel consumption rate(g/kW·h) | ≤180 |
Emission standard | China IV, China V |
Application | Heavy trucks |
